Поз.
Артикул
Описание
5
GASKET TRANSMISSION TO BELL HOUSING
10
SHIFT LEVER ,4 292379 FROM IDENT NO. 4 292380 SEE SPARE PARTS LIST
10
SHIFT LEVER
10
SHIFT LEVER REMOTE GEARSHIFT MECHANISM,4 291253
10
SHIFT LEVER
15
BUSHING PAWL TO ROD END,5 443047
20
BRACKET SHIFT LEVER BEARING,4 292379
25
VALVE (SHIFT LEVER VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
25
VALVE , Replaced By: A3852600057
30
SEAL RING ,4 411810
35
HOSE (PARTS KIT),4 411810
35
HOSE , Replaced By: A3019971182
40
HANDLE SHIFT LEVER
45
COVER SHIFT LEVER
50
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
55
WASHER RADIATOR TO RUBBER MOUNTING
55
WASHER , Replaced By: N000125010532
60
DECALCOMANIA GEARSHIFT LEVER KNOB
65
BOOT SHIFTING LEVER
65
BOOT , Replaced By: A3892680097
70
BRACKET LINE MOUNTING,4 411811
75
BRACKET LINE TO BRACKET
80
SERRATED WASHER BRACKET TO CAB FLOOR,4 411811
85
NUT BALL PIVOT TO LEVER
90
LOCK FUEL LINE
90
LOCK , Replaced By: A1409941045
95
SPACER TUBE BRACKET TO CAB
100
TAPPING SCREW. SHEET METAL SCREW FUEL LINE
105
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
107
SHIFTING ROD (TELESCOPIC TUBE)
108
PULL ROD
110
SHIFTING TUBE REAR
110
SHIFTING TUBE REMOTE GEARSHIFT MECHANISM
110
ROD REMOTE GEARSHIFT MECHANISM
110
SHIFTING ROD REMOTE GEARSHIFT MECHANISM
110
SHIFTING ROD REMOTE GEARSHIFT MECHANISM
110
SHIFTING ROD REMOTE GEARSHIFT MECHANISM,4 292379
110
SHIFTING TUBE REMOTE GEARSHIFT MECHANISM,4 292380
110
SHIFTING TUBE REMOTE GEARSHIFT MECHANISM,4 292380
110
SHIFTING ROD REMOTE GEARSHIFT MECHANISM,4 292380
115
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
117
SHIFTING TUBE (TELESCOPIC TUBE)
119
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
120
ROD END HYDRAULIC RELEASE
123
SHIFTING TUBE (TELESCOPIC TUBE)
125
CLAMPING PIECE SHIFTING ROD TO TRANSMISSION
130
SCREW CONNECTOR TO REAR SHIFTING ROD
130
SCREW , Replaced By: N304017010047
145
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
150
ROUND CORD RING. SEAL RING ROD END
155
SCREW SHIFTING ROD TO SHIFT LEVER
160
NUT STRAP TO BRACKET
160
NUT , Replaced By: N910113010000
165
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
175
JOINT SHIFTING ROD TO TRANSMISSION
175
JOINT SHIFTING ROD TO TRANSMISSION
175
JOINT , Replaced By: A3832680489
175
JOINT SHIFTING ROD TO TRANSMISSION
180
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
180
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
185
SEAL RING PISTON RINGS WABCO
190
SEAL RING SCREW FITTING WABCO
195
SEAL RING OUTSIDE WABCO
200
SCREW CONNECTOR TO REAR SHIFTING ROD
200
SCREW , Replaced By: N304017010047
205
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
210
NUT STRAP TO BRACKET
210
NUT , Replaced By: N910113010000
215
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
220
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
220
PIN , Replaced By: N001444008235
225
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
225
COTTER PIN LEVER TO ROD
230
SPRING WASHER SHIFTING CYLINDER TO YOKE
235
WASHER BETWEEN THE SHIFTING RODS
240
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
250
BRACKET SHIFT LEVER BEARING,4 292379
260
BUSHING SHIFT LEVER BEARING TO CAB FLOOR
265
SCREW SHIFTING ROD TO SHIFT LEVER,4 292379
270
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
275
NUT
280
SCREW , Replaced By: N000933008337
280
SCREW , Replaced By: A0099900101
280
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
285
SCREW SHIFTING TUBE TO TRANSMISSION
290
SCREW BRACKET TO CROSS CONNECTION STRUT
290
SCREW , Replaced By: N304017008034
295
SCREW SHIFTING ROD TO TRANSMISSION
300
FLANGE TRANSMISSION
305
FLANGE SHIFTING TUBE TO TRANSMISSION
310
SCREW SHIFTING TUBE TO TRANSMISSION
315
CONNECTOR TRANSMISSION
540
BALL
545
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
575
SLEEVE LINE MOUNTING
575
BUSHING , Replaced By: N915062002000
999
VALVE , Replaced By: A0002608157
999
THREADED BUSHING NEUTRAL POSITION
999
SEAL RING , Replaced By: N007603018100
999
SEAL RING NEUTRAL POSITION
999
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.00 MM
999
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.20 MM
999
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.40 MM
999
PIN NEUTRAL POSITION
999
CLEANERTO 000 434 22 01
999
CUP 3/2-WAY VALVE WABCO
999
VALVE GEAR CLUSTER SHIFT
999
SWITCH , Replaced By: A0005459009
999
HOLLOW SCREW , Replaced By: N915047008100
999
HANDLETO 000 434 23 01
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 403697, Replaced By: A0012605357
999
REPAIR KIT SHIFT LEVER VALVE
999
SWITCH , Replaced By: A0025458114
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
999
SENDER UNIT OVERREVVING
999
SENDER UNIT OVERREVVING
999
SEAL RINGTO 000 434 23 01
999
SEAL RING LEVER BEARING
999
HOSE , Replaced By: A3019971182
999
HANDLE , Replaced By: A3432600040
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
SHIFTING ROD SHIFTING ROD TO JOINT,4 291253-4 366027
999
BRACKET AT CLUTCH PEDAL UNIT
999
CONNECTOR REAR SHIFTING ROD
999
BRACKET FRONT SHIFTING ROD TO REAR SHIFTING ROD
999
SHIFT LEVER
999
COVER PLATE AT TRANSMISSION
999
BRACKET SENSOR CABLE TO FRONT AXLE
999
RUBBER PAD SHIFT LEVER BEARING TO CAB FLOOR
999
YOKE CONNECTOR,4 2630144 366027
999
YOKE CONNECTOR
999
BRACKET SHIFT LEVER BEARING TO CAB FLOOR
999
BRACKET , Replaced By: A6205240340
999
DECALCOMANIA NINE-SPEED
999
WASHER LEVER TO BRACKET 30X10.5X4 MM
999
WASHER , Replaced By: A4039900040
999
HOSE , Replaced By: A3019970682
999
BRACKET SOLENOID VALVE,4 411810
999
JOINT SHIFTING ROD TO TRANSMISSION
999
BRACKET AT ENGINE MOUNTING CONSOLE
999
SHIFTING ROD REAR,4 292379
999
SHIFTING ROD SHIFTING SHAFT
999
WASHER FRONT SHIFTING ROD TO REAR SHIFTING ROD,4 292379
999
TUBE. BUSHING CAB FLOOR COVERING
999
RUBBER RING SHIFT LEVER BEARING,4 292379
999
BRACKET COMPRESSED AIR LINES
999
BRACKET LINE MOUNTING
999
ROD FRONT, TRANSVERSE
999
SHIFTING TUBE REAR
999
BRACKET SHIFTING TRANSFER,LEFT
999
SHIFT LEVER
999
ROD REAR,5 018216
999
SHIFTING ROD FRONT, TRANSVERSE
999
ROD
999
SHIFTING ROD REAR,4 9211775 018215
999
SHIFT LEVER
999
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
999
KNOB (SHIFT LEVER HANDLE), TO BE ADAPTED DURING ASSEMBLY
999
SPACER TUBE SHIFTING TRANSFER,LEFT
999
PIN SHIFTING ROD TO JOINT
999
JOINT SHIFTING TRANSFER,LEFT,4 8557044 921176
999
RUBBER PAD SHIFTING TRANSFER,LEFT
999
BOOT SHIFTING ROD
999
KNOB , Replaced By: A6202600040
999
COVER SHIFT LEVER KNOB LESS GEARSHIFT DIAGRAM
999
JOINT SHIFTING TRANSFER,LEFT
999
BOOT SHIFT LEVER
999
WASHER BETWEEN FRONT AND REAR SHIFTING TUBES
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
FITTING , Replaced By: A0019903170
999
SEAL RING LINE CONNECTION
999
NUT SUCTION LINE TO OIL PUMP
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
HOLLOW SCREW HEATING CONNECTION
999
FITTING LINE CONNECTION TO FIRE WALL,5 726664
