Поз.
Артикул
Описание
6
ACCELERATOR PEDAL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6243000304
6
ACCELERATOR PEDAL , Replaced By: A6243000304
9
SCREW ACCELERATOR PEDAL
12
BALL PIVOT LOAD SENSOR
12
BALL PIVOT ACCELERATOR PEDAL,4 859026
15
NUT , Replaced By: N913004006001
15
NUT PUMP TO BRACKET
18
SHIM ACCELERATOR PEDAL
18
SHIM , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 859957, Replaced By: A6153010084
21
BOOT ACCELERATOR PEDAL,4 859957
21
BOOT ACCELERATOR PEDAL
24
SCREW ACCELERATOR PEDAL TO CAB M 6X25
27
SCREW PEDAL TO CAB FLOOR
30
SCREW VALVE TO BRACKET, Replaced By: N304014008002
33
NUT , Replaced By: N304032008006
36
STOP ACCELERATOR PEDAL
39
BALL SOCKET ROD TO ACCELERATOR PEDAL
42
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
45
BEARING TUBE ,5 151593, Replaced By: A6153000021, +001A6153000020
45
BEARING TUBE CONTROL SHAFT,5 151594
48
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
51
SHAFT ,5 151593, Replaced By: A6153000020, +001A6153000021
51
SHAFT CONTROL,5 151594
54
BALL PIVOT CONTROL SHAFT
57
LEVER (CONTROL LEVER)
60
BALL PIVOT CONTROL SHAFT
63
CLAMPING SLEEVE BEARING TUBE
66
SCREW , Replaced By: N304017008016
69
NUT , Replaced By: N913004008001
75
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
78
BALL SOCKET PULL ROD TO LEVER
81
NUT BALL PIVOT TO LEVER
84
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
90
BEARING BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 6 003030, Replaced By: A3973000436, +002A6153010088
90
BEARING BRACKET INTERMEDIATE BEARING
93
LEVER INTERMEDIATE BEARING
93
LEVER , Replaced By: A3973000028
99
BALL STUD. BALL PIVOT TOP B10X4,5 MM
105
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
108
COVERING , Replaced By: A6153010088
108
COVERING INTERMEDIATE BEARING
111
LOCK PLATE INTERMEDIATE BEARING
114
SCREW , Replaced By: N304017008034
115
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
120
ROD FROM INTERMEDIATE LEVER TO ENGINE
122
BALL SOCKET ROD TO BALL PIVOT
124
NUT TAIL LAMP TO BRACKET
126
SECURING CLIP. CIRCLIP
128
PIN ROD TO LEVER
130
WASHER BRACKET TO CROSS MEMBER
132
COTTER PIN ROD TO INTERMEDIATE LEVER
134
SPRING WASHER , Replaced By: N000137008212
999
SERRATED WASHER ACCELERATOR PEDAL TO CAB, ELIMINATED,NO LONGER REQUIRED
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
BRACKET CABLE HARNESS MOUNTING
999
CLAMP , Replaced By: A6739950001
999
CLAMP LINE MOUNTING
