Поз.
Артикул
Описание
144
HOUSING BELL HOUSING WITH BUSHINGS
144
HOUSING ,4 7439865 285575, Replaced By: A6202501205, +001A6202500155
147
BUSHING RELEASE SHAFT,BOTTOM
150
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
153
BUSHING ,5 285575, Replaced By: A6202510050, +001A6202500155, +001A0099971547
153
BUSHING RELEASE SHAFT,TOP
156
BUSHING RELEASE SHAFT,TOP 35X39 MM
159
SEAL RING RELEASE SHAFT,BOTTOM 40X52X11 MM
159
SEAL RING RELEASE SHAFT,TOP 40X52X7 MM
159
SEAL RING RELEASE SHAFT,TOP
162
COVER PLATE RELEASE SHAFT,TOP
165
SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 285575, Replaced By: A3852500014
165
REPAIR KIT , Replaced By: A3892500014
168
WASHER AS REQUIRED 1.3 MM
168
WASHER AS REQUIRED 1.20 MM
168
WASHER AS REQUIRED 1.00 MM
168
WASHER AS REQUIRED 0.80 MM
171
SEAL RING BOTTOM
174
SPACER WASHER RELEASE SHAFT,BOTTOM
177
LOCK RING RELEASE SHAFT,BOTTOM
180
RELEASE LEVER CLUTCH ACTUATION
184
SCREW , Replaced By: N000933012102
190
SCREW RADIATOR M 10X45
192
WASHER , Replaced By: N000125010532
198
RELEASE BEARING CLUTCH ACTUATION
198
RELEASE BEARING CLUTCH ACTUATION
202
SPRING RELEASE BEARING TO RELEASE LEVER
203
PLUG BELL HOUSING
203
PLUG BELL HOUSING
204
PLUG BELL HOUSING
204
COVER PLATE , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3972510083, +002A0002510183
205
SCREW , Replaced By: N304017008016
208
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
211
PLUG BELL HOUSING
214
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
217
HOSE RELEASE COLLAR LUBRICATION 220 MM
220
UNION SCREW RELEASE COLLAR LUBRICATION
223
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
226
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
228
NUT RELEASE BEARING LUBRICATION
230
GREASE NIPPLE RELEASE COLLAR LUBRICATION
230
INTERMEDIATE PIECE ,5 190179, Replaced By: A6209970088, +001A6209880135
234
CAP RELEASE BEARING LUBRICATION
234
GREASE CUP ,5 190179, Replaced By: A6209880135, +001A6209970088
238
LEVER (PARTS KIT),CLUTCH ACTUATION
238
LEVER CLUTCH ACTUATION TO 397 290 02 34
246
PIN CLUTCH ACTUATION
250
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019972141
250
SEAL RING CLUTCH ACTUATION
254
LOCK RINGTO 000 553 37 01,000 553 39 01,
255
SCREW , Replaced By: N304017010053
256
ROD END CLUTCH ACTUATION
258
WASHER LEVER TO RELEASE SHAFT,5 285575
258
COVER RELEASE SHAFT,TOP
258
WASHER , Replaced By: A6202540176
262
SEAL RING LEVER TO RELEASE SHAFT,5 285575
274
BRACKET SLAVE CYLINDER
278
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
282
SCREW , Replaced By: N304017010002
286
SLAVE CYLINDER , Replaced By: A0022951007
286
SLAVE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 368621, Replaced By: A0012958907
293
BOOT
294
VALVE , Replaced By: A3075530107
294
BLEEDER VALVE , Replaced By: A0004310265
294
VALVE CLUTCH SLAVE CYLINDER
302
PROTECTIVE CAP ,5 962906
302
PROTECTIVE CAP , Replaced By: A0004217187
306
REPAIR KIT CLUTCH SLAVE CYLINDER
306
REPAIR KIT , Replaced By: A0002900911
306
BOOT , Replaced By: A0005863129
306
REPAIR KIT CLUTCH SLAVE CYLINDER
310
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
314
SCREW , Replaced By: N304017010002
999
HOUSING
