Поз.
Артикул
Описание
10
SLIDING DOOR LEFT
10
SLIDING DOOR LEFT
10
SLIDING DOOR RIGHT
10
SLIDING DOOR RIGHT
20
WINDSCREEN GUIDE RAIL SLIDING DOOR RIGHT
20
WINDSCREEN GUIDE RAIL LEFT SLIDING DOOR
100
RETAINING RAIL RAIL,RIGHT
100
RETAINING RAIL RAIL,RIGHT
100
RETAINING RAIL LEFT RAIL
110
DOOR RETAINER REAR CENTRAL LEFT
120
BRACKET REAR CENTRAL LEFT
130
SCREW W SOCKET DRIVE LEFT M6X50
140
OVAL HEAD SLOTTED SCREW FASTENING OF ACTUATOR, LEFT M6X20
150
OVAL HEAD SLOTTED SCREW FASTENING OF ACTUATOR, LEFT M6X20
160
HEXAGON NUT W FLANGE LEFT TOP M6
200
GUIDE RAIL DOOR DOOR AT RIGHT, TOP
200
GUIDE RAIL DOOR LEFT DOOR,TOP
210
DOOR RETAINER FRONT TOP LEFT
210
DOOR RETAINER REAR TOP, RIGHT
220
CARRIAGE TOP RIGHT
220
CARRIAGE TOP LEFT
230
FILLISTER HEAD SCREW RIGHT BRACKET M8X18
240
CARRIAGE TOP, LEFT
300
GUIDE RAIL DOOR LEFT DOOR,BOTTOM
300
GUIDE RAIL DOOR RIGHT DOOR, BOTTOM
310
CARRIAGE FRONT BOTTOM LEFT
310
CARRIAGE FRONT BOTTOM RIGHT
320
BRACKET FRONT BOTTOM RIGHT
320
BRACKET BOTTOM LEFT
330
FILLISTER HEAD SCREW RIGHT BRACKET M8X18
340
OVAL HEAD SLOTTED SCREW FASTENING OF ACTUATOR, LEFT M6X20
350
BOLT AND WASHER ASSEMBLY HINGE TOP LEFT M8X25
360
DOOR RETAINER FRONT BOTTOM RIGHT
360
DOOR RETAINER FRONT BOTTOM LEFT
370
OVAL HEAD SLOTTED SCREW FASTENING OF ACTUATOR, LEFT M6X20
380
OVAL HEAD SLOTTED SCREW FASTENING OF ACTUATOR, LEFT M6X20
390
HEXAGON NUT W FLANGE LEFT BOTTOM M8
400
CARRIAGE REAR CENTRAL RIGHT
400
CARRIAGE REAR CENTRAL LEFT
410
BRACKET REAR CENTRAL LEFT
410
BRACKET CENTRAL TOP RIGHT
420
HEXAGON HEAD BOLT LEFT M8X30
430
GUIDE PIN AT LEFT BRACKET
440
BRACKET REAR CENTRAL LEFT
450
GUIDE WEDGE LEFT DOOR
450
GUIDE WEDGE RIGHT DOOR
450
GUIDE WEDGE RIGHT DOOR
460
GUIDE WEDGE RIGHT DOOR
460
GUIDE WEDGE RIGHT DOOR
470
THR.ROLL.FILL.HD SCREW BRACKET MOUNTING M6X20
500
COVER RAIL SLIDING DOOR RIGHT
510
RETAINING CLIP COVER RAIL
600
DOOR SEAL LEFT
620
DOOR SEAL BOTTOM RIGHT
620
DOOR SEAL BOTTOM RIGHT
640
SEALING RAIL TOP RIGHT
640
SEALING RAIL TOP RIGHT
650
BRACKET REAR CENTRAL RIGHT
700
FEED-THROUGH GROMMET LEFT DOOR
730
SUPPORT RIGHT REAR WINDOW
