Mercedes A0019909404 - БОЛТ М10

OM 442 LA 446.938 FROM PRODUCTION 01/2004

09 FUEL FILTER AND TURBOCHARGER - 001 ENGINE PARTS USED WITH CHARGE AIR COOLING IL.9

Поз.
Артикул
Описание
5
A4571880504
HOUSING OIL COOLER, ORDER ADDITIONALLY: N 000908 030002 U. N 0076030030400
20
N000908030012
SCREW PLUG
23
N000000010074
SCREW TO PLUG THE OIL PASSAGES
95
A4031840132
VALVE
98
A4039930201
SPRING BY-PASS VALVE
101
A4031840156
SCREW PLUG
104
N007603026104
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
108
A4039970230
SCREW PLUG
110
N000000001073
SEAL RING
113
A1119970330
SCREW PLUG, FILLING OIL DRAIN
116
N000000001069
SEALING RING
119
A0021887901
OIL COOLER
119
A0021884301
OIL COOLER
122
N917003026003
SEAL. GASKET , Replaced By: A3661880880
125
A1299900310
SCREW LOCKING BOLT M8X65,V 208920
131
A4421880580
GASKET OIL FILTER HEAD & OIL COOLER COVER WITH OIL COOLER TO CRANKCASE
134
N000000000428
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
134
A0019909404
SCREW SHIFTING ROD TO SHIFT LEVER
161
A3522036439
FLANGE (BLIND FLANGE)
164
N917003022003
GASKET HEATING PIPE TO ENGINE
167
N000000000276
SCREW BRACKET TO SIDE MEMBER M8X20
