Поз.
Артикул
Описание
173
GEAR DRIVE GEAR ON CAMSHAFT
176
SCREW CONNECTOR TO REAR SHIFTING ROD
179
GASKET
182
SCREW FAN TO CRANKSHAFT PULLEY
188
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
188
SCREW BRACKET TO EXHAUST PIPE BRACKET
188
SCREW , Replaced By: N304017008024
188
SCREW WATER PUMP COVER TO WATER PUMP HOUSING M 8X28
191
SPRING WASHER , Replaced By: N000137008212
191
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
194
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
197
LINE WATER INTAKE
197
LINE FROM CRANKCASE COOLING WATER INLET TO AIR COMPRESSOR
200
LINE
209
BRACKET AIR-COMPRESSOR-TO-CRANKCASE COOLING WATER RETURN LINE
212
CLAMP CABLE HARNESS MOUNTING
212
CLAMP , Replaced By: N916016010211
212
CLAMP , Replaced By: N000000001045
215
SCREW , Replaced By: N914146006102
215
SCREW CLAMP MOUNTING M 6X16
218
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
218
NUT , Replaced By: N913023006001
224
INTAKE PIPE AIR COMPRESSOR
227
CLAMP25-40X13 MM
227
LOOM TIE , Replaced By: N000000000668
227
CLAMP , Replaced By: A0069970490
230
FITTING AIR COMPRESSOR,CONNECTION: "10"
239
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
242
FITTING AT AIR COMPRESSOR
245
CLAMP25-40X13 MM
245
LOOM TIE , Replaced By: N000000000668
245
CLAMP , Replaced By: A0069970490
999
SEAL RING , Replaced By: A0149976148
999
CYLINDR. ROLLER BEARING , Replaced By: A0079813001
999
CAP , Replaced By: A4421310021
999
COMPRESSOR REP. SOLUTION MODIF. FRICTION BEARING 1-CYL. AIR COMPRESSOR OIL PAN SIDE, AIR COMPRESSOR 90 MM
999
SPRING WASHER , Replaced By: N000137008212
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
