Поз.
Артикул
Описание
7
BEARING HOUSING RANGE OF DELIVERY, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
7
WATER PUMP. BEARING HOUSING RANGE OF DELIVERY, TO BE USED AS A NEW PART ONLY, 910 10/50,20/60 025170 UNTIL PRODUCTION STOP 910 12/52,22/62 023540 UNTIL PRODUCTION STOP 931 10/50,20/60 011424 931 12/52,22/62 001229 932 10/50,20/60 000090 932 12/52,22/62 000001 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
7
WATER PUMP , Replaced By: A1102001720
7
WATER PUMP
14
GROOVED BALL BEARING
14
BEARING SHAFT,WATER PUMP WITH SHAFT, FROM ENGINE 920 10/50,20/60 027500 ALSO INSTALLED ON 021530-021695,023811-024099 920 12/52,22/62 006324 ALSO INSTALLED ON 004879-004924,005379-005420 921 001317 ALSO INSTALLED ON 001006-001090 923 10/50,20/60 026789 ALSO INSTALLED ON 020179-020265,022508-022747 923 12/52,22/62 004259 ALSO INSTALLED ON 003052-003057,003466-003519 924 10/50,20/60 000643 ALSO INSTALLED ON 000482-000487,000541-000548 926 10/50,20/60 001142 ALSO INSTALLED ON 000891-000897,000990-001003 928 000338 ALSO INSTALLED ON 000281-000299 924 12/52,22/62 000027 926 12/52,22/62 000030
21
HUB , 912 10/50,20/60 099074 912 12/52,22/62 088016 931 10/50,20/60 000012 931 10/50,20/60 011424 931 12/52,22/62 001229 932 10/50,20/60 000090 932 12/52,22/62 000001
21
HUB
23
GASKET KIT WATER PUMP, FROM ENGINE 920,924 10/50,20/60 000067 920,924 12/52,22/62 000013 923,926 10/50,20/60 000026 923,926 12/52,22/62 000005
23
GASKET KIT , Replaced By: A1102002901
23
REPAIR KIT , Replaced By: A1102000060
25
GASKET KIT , Replaced By: A6172000060
25
GASKET KIT , Replaced By: A6172001001
25
GASKET KIT WATER PUMP
28
HOUSING
28
HOUSING , Replaced By: A1152010201
42
GASKET , Replaced By: A6162010180
42
GASKET
43
GASKET WATER PUMP HOUSING
43
GASKET , Replaced By: A6162010080
45
SCREW DOOR CHECK TO FRONT DOOR
47
WASHER
47
WASHER , Replaced By: A3129901940
49
SCREW , Replaced By: N304017008030
49
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
50
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
50
SCREW , Replaced By: N304017008030
52
PULLEY , Replaced By: A6152052010
52
PULLEY
52
PULLEY ONE-GROOVE
56
FAN
56
FAN
56
FAN
56
FAN , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6162050906
63
FAN DRIVE
70
SCREW BRACKET TO INTAKE MANIFOLD
70
SCREW BEARING BRACKET TO TRANSMISSION
70
SCREW , Replaced By: N007984008003
77
SPRING WASHER , Replaced By: N000137008212
77
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
84
SCREW
86
SCREW FAN TO FAN COUPLING M6X14
86
COMBINATION BOLT FAN TO FAN COUPLING M6X14, Replaced By: N000000004776
90
HUB RING
94
HUB RING
94
HUB RING FAN AND PULLEY TO WATER PUMP
94
HUB RING
100
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
100
SCREWM 8X40
100
SCREW CONNECTOR
100
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
100
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
100
SCREW , Replaced By: N000933008337
100
SCREW , Replaced By: A0099900101
102
SPRING WASHER , Replaced By: N000137008212
102
SPRING WASHER LICENSE PLATE TO BRACKET
102
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
114
V-BELT
114
V-BELT
114
V-BELT12.5X1030
114
V-BELT12.5X1030
999
V-BELT WATER PUMP AND ALTERNATOR 12.5X1000
999
FAN
999
WATER PUMP , Replaced By: A1102001720
999
WATER PUMP. BEARING HOUSING , Replaced By: A1152001520
999
WATER PUMP
999
FAN
999
HUB RING
999
WASHER , Replaced By: A3129901940
999
FAN
999
FOLLOWER ,940 10/50,20/60 082336
999
FAN DRIVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 940 10/50,20/60 252693, Replaced By: A6022000122
999
PULLEY , Replaced By: A6152052010
999
BASIC ENGINE , ORDER LONG BLOCK IN COMBINATION WITH APPLICATION DATA AND ASSIGNMENT TO ENGINE
999
BASIC ENGINE , ORDER LONG BLOCK IN COMBINATION WITH APPLICATION DATA AND ASSIGNMENT TO ENGINE
999
FAN
999
FAN DRIVE
999
FAN
999
FAN DRIVE
999
SPRING WASHER , Replaced By: N000137008212
999
SCREW TO SECURE SET NUT M 10X1.5X45
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW BRACKET ON LOAD SENSOR
999
SCREW , Replaced By: N304017008021
999
SCREW FITTING TO TRANSMISSION M8X32
999
COMBINATION BOLT , Replaced By: N000933006103, +001N000137006204
999
COMBINATION BOLT FAN TO FAN COUPLING M6X14, Replaced By: N000000004776
