Поз.
Артикул
Описание
590
VALVE PARKING BRAKE WABCO
591
VALVE PARKING BRAKE KNORR
591
VALVE PARKING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
592
PROTECTIVE CAPTO BOSCH
592
PROTECTIVE CAPTO WABCO
592
PROTECTIVE CAPKNORR
593
HANDLETO 002 430 29 81,WABCO
594
HANDLETO 001 430 08 81,BOSCH
594
HANDLETO 001 430 08 81,BOSCH
595
COVERTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
596
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
597
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
598
ACTUATING PARTTO 001 430 07 81/20 81
599
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
600
BUSHINGTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
601
VALVE. REPAIR KIT HAND BRAKE LEVER TO 001 430 65 81
601
LEVER , Replaced By: A0034302881
602
PINTO 002 430 90 81
603
HANDLE (PARTS KIT) TO 001 430 07 81/20 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
604
REPAIR KITTO 001 430 56 81,001 430 57 81
604
REPAIR KIT , Replaced By: A0034303181
605
REPAIR KITTO BOSCH
605
REPAIR KITBOSCH
606
SEAL RING FUEL LINE TO FEED PUMP
607
HOLLOW SCREW FUEL LINE TO FEED PUMP
607
HOLLOW SCREW , Replaced By: N915036010108
608
SCREW PARKING BRAKE VALVE TO WINDOW SILL
610
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
618
DISTRIBUTOR EXHAUST BRAKE VALVE LINE CONNECTION
622
SHIM
626
SCREW APPARATUS PLATE M 6X45
626
SCREW , Replaced By: N304017006027
628
WASHER COMPRESSED AIR LINE TO BRACKET
628
WASHER , Replaced By: N009021006208
630
NUT PUMP TO BRACKET
630
NUT , Replaced By: N913004006001
634
SEAL RING LINE CONNECTION
636
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
636
SCREW PLUG , Replaced By: N000908012009
638
HOLLOW SCREW HEATING CONNECTION
999
BOOTTO 006 420 28 18,15 18,WABCO
999
GUIDE , Replaced By: N071752014000
999
ADAPTER FITTING , Replaced By: A0004296634
999
ADAPTER FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22"
999
ADAPTER FITTING , Replaced By: A0004296934
999
HANDLETO 001 430 17 81,KNORR
999
REPAIR KITTO 001 430 18 81/78 81
999
REPAIR KIT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO WABCO NR.0182, Replaced By: A0004306260
999
REPAIR KIT , Replaced By: A0014300460
999
BUSHING , Replaced By: N915062004000
999
SPRING , Replaced By: A0009935205
999
SCREW. UNION SCREW LINE CONNECTION
999
VALVE , Replaced By: A0034291644
999
VALVE , Replaced By: A0014306581
999
VALVE , Replaced By: A0024300381
999
SEAL RING , Replaced By: A0009971548
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART TO 007 420 68 18,007 420 70 18,WABCO
999
REPAIR KIT TRISTOP CYLINDER TO 006 420 25 18,WABCO
999
REPAIR KIT , Replaced By: A0004301160, +001A0004310273, +001A0004318383, +002A0004312185
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
BRACKET AIR RESERVOIRS I AND II,5 586938
999
STOP LIGHT SWITCH , Replaced By: A0005457009
999
BRACKET , Replaced By: A3525422840
999
LINE , Replaced By: A3834290801
999
LINE , Replaced By: A6194290801
999
BEARING BRACKET ,5 197194, Replaced By: A3634230033
999
LINE , Replaced By: A6254293501
999
LOCK (PROTECTION AGAINST TORSION),5 934168
999
WASHER , Replaced By: N000125017016
999
WASHER BRACKET TO FRAME
999
NUT , Replaced By: N308675016001
999
FITTING , Replaced By: A0009907871
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
YOKE , Replaced By: A0009961401
999
FITTING ,4 667210
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
999
PULL ROD , Replaced By: N900331010671
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
