Поз.
Артикул
Описание
805
VALVE (RELAY VALVE) BOSCH
805
VALVE (RELAY VALVE) GRAU
805
VALVE (RELAY VALVE) KNORR
805
VALVE (RELAY VALVE) WABCO
807
SEAL RING22.3X2.4 MM,GRAU
809
VALVE SEATGRAU
812
SEAL RINGTO 000 429 28 95,GRAU
814
SEAL RING28X2 MM,GRAU
816
SEAL RING86X2 MM,GRAU
818
GASKET34X2X6 MM,GRAU
820
REPAIR KITTO 001 429 20 44,BOSCH
820
REPAIR KITWABCO
820
REPAIR KIT , Replaced By: A0004201071
820
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
820
VALVEBOSCH
820
REPAIR KIT , Replaced By: A0004301109
820
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
820
REPAIR KITKNORR
830
O-RING CHECK VALVE TO AIR RESERVOIR
832
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
832
THRUST RING CHECK VALVE TO AIR RESERVOIR
834
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
838
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
840
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
842
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
844
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
848
FITTING DIAPHRAGM CYLINDER,CONNECTION:
850
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
852
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
856
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
859
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
862
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
868
BRACKET RELAY VALVE,5 484806
872
BRACKET BRAKE LINE
874
BRACKET RELAY VALVE, NOT USED
875
NUT , Replaced By: N913004008001
875
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
875
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
878
SCREW END PIECE TO EXHAUST PIPE M 10X25
880
NUT , Replaced By: N910113010000
880
NUT STRAP TO BRACKET
884
FITTING LEFT AND RIGHT BRAKE HOSES
886
NUT BRACKET TO SIDE MEMBER
890
FITTING DIAPHRAGM CYLINDER,CONNECTION:
892
GLAND , Replaced By: A0019901967
892
SEAL CONE LINE CONNECTION
894
UNION NUT LINE CONNECTION, Replaced By: N000000006239
894
UNION NUT LINE CONNECTION
898
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
902
CLAMP HOSE TO FITTING AND TO OIL TANK
902
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
905
FITTING DIAPHRAGM CYLINDER,CONNECTION:
907
GLAND , Replaced By: A0019901967
907
SEAL CONE LINE CONNECTION
909
UNION NUT LINE CONNECTION, Replaced By: N000000006239
909
UNION NUT LINE CONNECTION
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
PULL ROD , Replaced By: N900331010671
999
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
FITTING ,4 667210
999
YOKE , Replaced By: A0009961401
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
FITTING , Replaced By: A0009907871
999
NUT , Replaced By: N308675016001
999
WASHER BRACKET TO FRAME
999
WASHER , Replaced By: N000125017016
999
LOCK (PROTECTION AGAINST TORSION),5 934168
999
LINE , Replaced By: A6254293501
999
BEARING BRACKET ,5 197194, Replaced By: A3634230033
999
LINE , Replaced By: A6194290801
999
LINE , Replaced By: A3834290801
999
BRACKET , Replaced By: A3525422840
999
STOP LIGHT SWITCH , Replaced By: A0005457009
999
BRACKET AIR RESERVOIRS I AND II,5 586938
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
REPAIR KIT , Replaced By: A0004301160, +001A0004310273, +001A0004318383, +002A0004312185
999
REPAIR KIT TRISTOP CYLINDER TO 006 420 25 18,WABCO
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART TO 007 420 68 18,007 420 70 18,WABCO
999
SEAL RING , Replaced By: A0009971548
999
VALVE , Replaced By: A0024300381
999
VALVE , Replaced By: A0014306581
999
VALVE , Replaced By: A0034291644
999
SCREW. UNION SCREW LINE CONNECTION
999
SPRING , Replaced By: A0009935205
999
BUSHING , Replaced By: N915062004000
999
REPAIR KIT , Replaced By: A0014300460
999
REPAIR KIT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO WABCO NR.0182, Replaced By: A0004306260
999
REPAIR KITTO 001 430 18 81/78 81
999
HANDLETO 001 430 17 81,KNORR
999
ADAPTER FITTING , Replaced By: A0004296934
999
ADAPTER FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22"
999
ADAPTER FITTING , Replaced By: A0004296634
999
GUIDE , Replaced By: N071752014000
999
BOOTTO 006 420 28 18,15 18,WABCO
