Поз.
Артикул
Описание
6
BEARING BRACKET CLUTCH PEDAL
6
BEARING BRACKET CLUTCH, IN CASE OF PEDAL BEARING BRACKET WITH SHIMS,DELIVER ADDITIONALLY: 3X 000939 008136,1X 620 290 03 34 UP TO IDENT NO. 5 238024, SEE SERVICE INFORMATION 29/4
6
BEARING BRACKET ,4 247126 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 655107, Replaced By: A3812901219
12
PEDAL CLUTCH PEDAL,4 915383
12
PEDAL CLUTCH PEDAL,4 915383
12
PEDAL CLUTCH PEDAL,4 915383
12
PEDAL , 415 5 014669 416 5 000516 417 4 972024, Replaced By: A6202900216
18
PEDAL CLUTCH,5 238025
18
PEDAL CLUTCH,5 238025
21
PEDAL CLUTCH,5 238025
24
SCREW CLUTCH PEDAL
24
SCREW CLUTCH PEDAL
24
SCREW CLUTCH PEDAL
30
NUT
30
NUT
30
NUT
30
NUT , Replaced By: N304035008001
36
SPRING (DEAD CENTER SPRING) 37 MM
36
SPRING (DEAD CENTER SPRING) 35 MM
36
SPRING (DEAD CENTER SPRING) 23.2 MM
48
SPRING CLUTCH PEDAL RESET
48
SPRING CLUTCH PEDAL RESET
48
SPRING CLUTCH PEDAL RESET
48
SPRING , Replaced By: A3819930710
54
SPRING RETAINER SPRING TO PUSH ROD
60
SPRING RETAINER SPRING TO PUSH ROD
66
ROD OVER-CENTER ACTING SPRING
66
ROD OVER-CENTER ACTING SPRING
72
NEEDLE BEARING JOINT TO PIN
72
NEEDLE BEARING JOINT TO PIN
72
NEEDLE BEARING JOINT TO PIN
72
NEEDLE BEARING JOINT TO PIN
80
NUT PUSH ROD
80
NUT , Replaced By: N308675010000
86
PIN CLUTCH PEDAL,5 238024
86
PIN CLUTCH PEDAL,5 238025
86
PIN PUSH ROD TO PEDAL
86
PIN PUSH ROD TO PEDAL
92
WASHER BRACKET TO CROSS MEMBER
98
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
104
REPAIR KIT DEAD CENTER SPRING
104
REPAIR KIT DEAD CENTER SPRING
104
REPAIR KIT DEAD CENTER SPRING, DELIVER ADDITIONALLY:1X 381 993 06 01
104
REPAIR KIT , Replaced By: A3812910333, +001A3812910674, +002A0002910491, +002A3092910091, +002A0059814410, +002A1109930501
104
ROD OVER-CENTER ACTING SPRING
110
MASTER CYLINDER CLUTCH,LESS DE-AERATION
110
MASTER CYLINDER CLUTCH,5 374582
110
MASTER CYLINDER , Replaced By: A0012953006
110
MASTER CYLINDER CLUTCH,LESS DE-AERATION
110
MASTER CYLINDER CLUTCH
116
PROTECTIVE CAPTO 001 295 08 06
116
BOOTTO 001 295 30 06
122
BLEEDER VALVE , Replaced By: A0004310265
122
VALVE , Replaced By: A3075530107
122
VALVE CLUTCH SLAVE CYLINDER
126
INTERMEDIATE PIECE CLUTCH MASTER CYLINDER
128
PROTECTIVE CAP , Replaced By: A0004217187
128
PROTECTIVE CAP ,5 962906
134
PLUG
134
PLUG , Replaced By: A0009971186
134
PLUG
140
REPAIR KIT TO MASTER CYLINDER HAVING SYNTHETIC PISTON TO 001 295 60 06
140
REPAIR KIT TO MASTER CYLINDER HAVING SYNTHETIC PISTON, I.D., 20.6 MM, TO 001 295 71 06,5 374582
140
REPAIR KIT MASTER CYLINDER
140
REPAIR KITTO 001 295 35 06
140
REPAIR KIT MASTER CYLINDER
146
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
146
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING M 6X60
152
VALVE 3/2-WAY VALVE
152
VALVE 3/2-WAY VALVE
157
GASKET KIT 3/2-WAY VALVE
162
LOCK RING LINE CONNECTION
162
SEAL RING , Replaced By: A0009940747
167
LOCK LINE CONNECTION
167
LOCK , Replaced By: A0009945448
172
SCREW. UNION SCREW LINE CONNECTION
172
SCREW. UNION SCREW , Replaced By: A0009973734
177
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
177
BREATHER , Replaced By: A3933280065
177
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
182
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
185
WASHER VALVE TO BRACKET
185
WASHER , Replaced By: N001440027000
187
NUT SUCTION LINE TO OIL PUMP
187
NUT SUCTION LINE TO OIL PUMP
192
BRACKET SPLITTER-BOX PILOT VALVE
192
BRACKET 3/2-WAY VALVE, UP TO IDENT NO.5 238024,FROM IDENT NO. SEE GROUP 29
192
BRACKET PEDAL BEARING BRACKET
192
BRACKET 3/2-WAY VALVE, UP TO IDENT NO.5 238024,FROM IDENT NO. SEE GROUP 29
192
BRACKET 3/2-WAY VALVE TO PEDAL BEARING BRACKET
192
BRACKET PEDAL BEARING BRACKET
197
SCREW COVER PLATE TO BRACKET
197
SCREW COVER PLATE TO BRACKET
197
SCREW BRACKET ON LOAD SENSOR
202
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
207
WASHER COMPRESSED AIR LINE TO BRACKET
207
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
