Поз.
Артикул
Описание
42
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
44
FITTING (PARTS KIT),LINE RUPTURE
44
FITTING , Replaced By: A0029905971
54
BANJO UNION HEATING CONNECTION,K 169122
54
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
504
VALVE (RELAY VALVE) KNORR
504
VALVE (RELAY VALVE) KNORR
504
VALVE (RELAY VALVE) BOSCH
504
VALVE (RELAY VALVE) GRAU
504
VALVE (RELAY VALVE) WABCO
508
SEAL RING22.3X2.4 MM,GRAU
510
VALVE SEATGRAU
512
SEAL RINGTO 000 429 28 95,GRAU
514
SEAL RING28X2 MM,GRAU
516
SEAL RING86X2 MM,GRAU
518
GASKET34X2X6 MM,GRAU
522
VALVEBOSCH
522
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
522
REPAIR KIT , Replaced By: A0004201071
524
REPAIR KITTO 003 429 53 44,KNORR
524
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
524
REPAIR KIT , Replaced By: A0004301109
524
REPAIR KITWABCO
527
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
528
THRUST RING CHECK VALVE TO AIR RESERVOIR
528
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
529
O-RING CHECK VALVE TO AIR RESERVOIR
541
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
544
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
550
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
550
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
550
NUT , Replaced By: N913004008001
558
BRACKET RELAY VALVE TO CROSS MEMBER
564
SCREW PIPE CLAMP
564
SCREW , Replaced By: N304017008021
566
WASHER BRACKET TO CROSS MEMBER
568
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
568
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
568
NUT , Replaced By: N913004008001
890
VALVE PARKING BRAKE VALVE KNORR
890
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0024309981
890
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
890
VALVE PARKING BRAKE VALVE BOSCH
890
VALVE PARKING BRAKE VALVE KNORR
890
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0024309881
890
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
890
VALVE PARKING BRAKE VALVE BOSCH
893
HANDLETO BOSCH
893
HANDLETO WABCO
902
REPAIR KITTO 002 430 98 81,99 81,KNORR
902
REPAIR KITTO BOSCH
902
REPAIR KITTO 001 430 56 81,001 430 57 81
902
REPAIR KIT , Replaced By: A0034303181
905
SCREW PARKING BRAKE VALVE TO WINDOW SILL
908
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
911
COUPLING FROM CHECK VALVE TO PARKING BRAKE VALVE
914
SEAL RING
999
REPAIR KIT , Replaced By: A0004300207
999
REPAIR KITTO 000 429 26 95,KNORR
999
VALVEWABCO
999
CONNECTOR REPAIR SIZE
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLEKNORR
999
PLUG
999
PROTECTIVE CAPTO WABCO
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPKNORR
999
VALVE , Replaced By: A0024314006
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART KNORR,K 262627
999
REPAIR KIT. BRAKE CYLINDER DIAPHRAGM PART TO 007 420 42 18, KNORR
999
VALVE , Replaced By: A0024312706
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 433281
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
VALVE (CHECK VALVE) WABCO
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KIT BRAKE POWER REGULATOR
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
ADHESIVE FOIL GUIDE SIGN
999
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
UNION NUT LINE CONNECTION
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
