Поз.
Артикул
Описание
42
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
56
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
56
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
148
TEST CONNECTION
589
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR,5 234164
589
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE,5 234164
589
BRAKE PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
590
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
590
REPAIR KIT VALVE BOSCH
590
REPAIR KIT COVERING TO 001 431 36 12
590
REPAIR KIT COVERING BOSCH
590
REPAIR KIT BRAKE POWER REGULATOR BOSCH
590
REPAIR KIT BRAKE POWER REGULATOR WABCO
598
GUIDE SIGN LOAD-DEPENDING BRAKE,5 192790
598
GUIDE SIGN AUTOMATIC,WITH CAST ENCLOSURE
599
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
605
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
606
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
611
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
611
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
611
NUT , Replaced By: N913004008001
613
SCREW BRACKET TO SIDE MEMBER
615
NUT COMBINATION CYLINDER TO BEARING BRACKET
615
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
616
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
616
LEVER , Replaced By: A6744310039
622
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
625
CONNECTOR PULL ROD TO LEVER
627
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
628
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
628
CLAMP , Replaced By: N000000000665
635
WASHER EXHAUST MUFFLER TO STRAP
635
WASHER , Replaced By: N000125008443
636
COTTER PIN PULL ROD
637
NUT
638
METAL SPRING BELLOWS ,5 557359
638
METAL SPRING BELLOWS ,5 557359
638
METAL SPRING BELLOWS BRAKE POWER REGULATOR CONTROL, NOT USED
648
LOCK WASHER FITTING TO BRACKET
649
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
REPAIR KIT , Replaced By: A0024292844
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
FITTING LEFT AND RIGHT BRAKE HOSES
999
REPAIR KITTO 000 429 26 95,KNORR
999
VALVEWABCO
999
REPAIR KIT , Replaced By: A0004205455
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
CONNECTOR REPAIR SIZE
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLEKNORR
999
PLUG
999
PROTECTIVE CAPTO WABCO
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPKNORR
999
VALVE , Replaced By: A0024314006
999
ELBOW FITTING DELIVERY LINE TO PUMP
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
VALVE REPAIR KIT
999
VALVE , Replaced By: A0024312706
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING LINE MOUNTING
999
ELBOW FITTING ,5 433281
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
VALVE (CHECK VALVE) WABCO
999
VALVE (PRESSURE LIMIT VALVE)
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KIT BRAKE POWER REGULATOR
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
SEAL RING8X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING4 X 1.50 MM, 415 5 014668 416 5 000515 417 4 972023
999
CHAIN LOCK LINK ,4 652830
999
SEAL RING5X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING BRAKE HOSE
999
BRACKET , Replaced By: A3604292940
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
BRACKET , Replaced By: A3604292440
999
ADHESIVE FOIL GUIDE SIGN
999
PROTECTIVE TUBE , Replaced By: N073379008200
999
BRACKET LEFT FRONT BRAKE HOSE, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET RIGHT FRONT BRAKE HOSE, TO BE ADAPTED DURING ASSEMBLY
999
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
999
BRACKET METAL SPRING BELLOWS
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
FITTING , Replaced By: A0019902771
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
HOSE HAND BRAKE VALVE BLEEDING 100 MM, ORDER BY THE METER
999
NUT CHECK VALVE TO AIR RESERVOIR
999
NUT BRACKET TO SIDE MEMBER
999
UNION NUT LINE CONNECTION
999
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
