Поз.
Артикул
Описание
505
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
510
REPAIR KIT
510
REPAIR KIT , Replaced By: A0015860843
513
SEAL RING LINE CONNECTION
515
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
517
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
517
ELBOW FITTING , Replaced By: A0004294638
519
NUT CHECK VALVE TO AIR RESERVOIR
521
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
523
O-RING CHECK VALVE TO AIR RESERVOIR
525
PIN TEST CONNECTION TO REAR AXLE
525
SPACER TUBE , Replaced By: A3872640974
526
SCREW VALVE TO CAB M 8X85
527
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
528
NUT
900
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
905
REPAIR KITTO 000 430 55 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
905
REPAIR KIT , Replaced By: A0004305760
911
SEAL RING FUEL LINE TO FEED PUMP
913
FITTING
913
FITTING , Replaced By: A0039979972
915
BRACKET HAND BRAKE VALVE
916
SCREW ACCELERATOR PEDAL TO CAB M 6X25
962
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
965
T-FITTING 3/2-WAY VALVE,CONNECTIONS: "30,50"
967
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
969
LOCK NUT
995
BRACKET OIL LINE MOUNTING
995
BRACKET , Replaced By: A3464296040
999
CLAMP ,K 147121, Replaced By: N000000000319
999
CLAMP , Replaced By: N916016008200
999
CLAMP , Replaced By: A3604300143
999
BOOTTO 006 420 28 18,15 18,WABCO
999
BRAKE CYLINDER , Replaced By: A0014203524, +002N913004016004
999
BRAKE CYLINDER , Replaced By: A0014204024, +002N913004016004
999
BRAKE CYLINDER , Replaced By: A0014203824, +002N913004016004
999
FITTINGWABCO
999
GUIDETO 006 420 28 18,WABCO
999
DIAPHRAGMTO 008 420 23 18,WABCO
999
CUP , Replaced By: A0004215286
999
CUPWABCO
999
CUPKNORR
999
SEAL RING , 019908
999
SEAL RING , 019908
999
PROTECTIVE CAP , 019909 880101
999
PROTECTIVE CAP , 019909 880101
999
CUPTO 006 420 28 18,WABCO
999
PROTECTIVE CAPTO 008 420 62 18,KNORR
999
LINE , Replaced By: A0005516256
999
LINE , Replaced By: A0005516456
999
CONNECTOR , Replaced By: A0004312031, +001N074302022304
999
THRUST RING SUCTION LINE TO OIL PUMP
999
DIAPHRAGM
999
ADAPTER FITTING FLUID RESERVOIR TO BRACKET
999
DIAPHRAGM
999
DIAPHRAGMTO 001 429 48 44
999
REPAIR KITTO 002 431 15 06,WABCO, 975 300 750 0,5 161700
999
REPAIR KIT DIAPHRAGM PART TO 006 420 28 18, WABCO
999
REPAIR KITKNORR 010 420 73 18
999
VALVE , Replaced By: A0004305681
999
VALVE HAND BRAKE VALVE,A 069205
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KITTO 000 430 56 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE HAND BRAKE VALVE KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE HAND BRAKE VALVE KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
DIAPHRAGMTO 001 431 90 06,GRAU,5 148812
999
DIAPHRAGM , Replaced By: A0004314128
999
DIAPHRAGMTO 008 420 60 18,62 18,KNORR
999
DIAPHRAGM , Replaced By: A0004314128
999
GASKET34X2X6 MM,GRAU
999
TEST CONNECTION
999
VALVE SEATWABCO,002 0,012 0
999
VALVE DISCTO 001 431 90 06,GRAU,5 148812
999
VALVE DISCTO 001 431 90 06,GRAU,5 148812
999
VALVE SEATGRAU
999
VALVE SEATTO 001 431 90 06,GRAU,5 148812
999
VALVEWABCO,002 0,012 0
999
VALVETO 001 431 90 06,GRAU,5 148812
999
STRAINERTO 001 431 90 06,GRAU,5 148812
999
DIAPHRAGMTO 008 420 61 18,009 420 22 18
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
PRESSURE REGULATOR , Replaced By: A0004317906
999
PROTECTIVE CAPTO 001 431 90 06,GRAU,5 148812
999
CUPGRAU
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
REPAIR KITTO 005 420 08 18,005 420 93 18
999
REPAIR KIT , Replaced By: A0004305860
999
EXPANSION PLUG CAB REAR PANEL
999
SEALING CORD SUCTION LINE TO OIL PUMP
999
CROSS FITTING ,880102
999
SPRINGWABCO,002 0,012 0
999
SPRINGWABCO,002 0,012 0
999
CLAMP LINE CONNECTION
999
FITTING RELAY VALVE,CONNECTION: "1,2"
999
PLUGTO 009 420 22 18,008 420 20 18
999
PLUG
999
BRAKE CYLINDER LEFT WABCO,4 337020 FROM IDENT NO. 4 337021, SEE SEPARATE SPARE LIST 739.001
999
BRAKE CYLINDER LEFT GRAU,4 337020 FROM IDENT NO. 4 337021, SEE SEPARATE SPARE LIST 739.001
999
BRAKE CYLINDER LEFT KNORR,4 337020 FROM IDENT NO. 4 337021, SEE SEPARATE SPARE LIST 739.001
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
SPRING
999
CUP , Replaced By: A0004216186
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
GASKET , Replaced By: A0004311980
999
REPAIR KIT , Replaced By: A0004301107
999
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
999
FITTING SHUTTLE VALVE,CONNECTION: "20"
999
LOOM TIE , Replaced By: N900288014002
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART KNORR,K 262627
999
REPAIR KIT DIAPHRAGM PART TO 008 420 62 18, KNORR
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART WABCO,K 262627
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
REPAIR KIT , Replaced By: A0025865242
999
REPAIR KIT , Replaced By: A0004301168
999
REPAIR KITKNORR
999
REPAIR KITKNORR
999
REPAIR KITTO 000 431 79 06,WABCO,475 304 201 0,
999
REPAIR KIT , Replaced By: A0024301560
999
REPAIR KITGRAU,5 148812
999
REPAIR KIT , Replaced By: A0034303881
999
FITTING BRAKE HOSE,5 418584
999
LOOM TIE , Replaced By: N916017020000
999
SEAL RINGTO 001 431 57 05,4 868986
999
WHEEL BRAKE CYLINDER , 019908, Replaced By: A0034204718, +002N007603022100, +002N074298022202
999
REPAIR KITTO 000 430 66 81,000 430 67 81, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SEAL RING BRAKE SHOE ROLLER
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RINGTO 001 431 90 06,GRAU,5 148812
999
SEAL RINGTO 001 431 90 06,GRAU,5 148812
999
SEAL RINGTO 001 431 90 06,GRAU,5 148812
999
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
999
SEAL RING BRAKE SHOE BEARING, 036465
999
SEAL RING6.07X1.78 MM,WABCO,002 0,012 0
999
SEAL RING32.99X2.62 MM,WABCO,002 0,012 0
999
SEAL RING12.42X1.78 MM,WABCO,002 0,012 0
999
SEAL RING17.12X2.62 MM, 402,407 FROM CHASSIS 657000
999
SEAL RING , 019908
999
SEAL RING , 019908
999
HOSE , TO 004 420 11 18,005 420 94 18
999
BUSHINGTO 301 420 00 39
999
GROMMET
999
THRUST PIECE BRAKE SHOE TO BRAKE ANCHOR
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
BRACKET RELAY VALVE,600893 350.033 UP TO IDENT NO. 680088
999
REPAIR KIT BRAKE SHOE ROLLER, UP TO CHASSIS 4 387020, FROM CHASSIS SEE SPARE PARTS LIST 739.0
999
BEARING BRACKET RIGHT
999
BRACKET
999
REPAIR KIT ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3 NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIER KIT
999
BEARING BRACKET RIGHT,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
999
BRACKET FUEL LINE
999
BRACKET , Replaced By: A3464296040
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: A6739950001
999
BEARING BRACKET WHEEL CYLINDER,5 197195
999
PROTECTIVE PLATE , UP TO REAR AXLE 060665, Replaced By: A3664200944, +012N000934016002, +004N000936016007, +008N000960016161
999
SHIM VALVE TO CAB, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BEARING BRACKET ,5 197194, Replaced By: A3634230033
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
SCREW CLAMP MOUNTING M 6X16
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
COTTER PIN REAR PANEL TO SUBSTRUCTURE
999
COTTER PIN WHEEL CYLINDER TO SLACK ADJUSTER,4 637963
999
COTTER PIN COUPLING FLANGE TO P.T.O.
999
WASHER PROTECTIVE PLATE TO FRONT EXHAUST PIPE
999
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
999
LOCK RING SHIFT LEVER BEARING
999
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
999
SCREW , Replaced By: N304017008021
999
NUT BALL PIVOT TO LEVER
999
NUT STRAP TO SUPPORT
999
NUT BRAKE ANCHOR PLATE TO REAR AXLE
999
NUT
999
SCREW , Replaced By: N308676012015
999
SCREW , Replaced By: N308676012012
999
SCREW , Replaced By: N308676012038
999
WASHER , Replaced By: N007349013005
999
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
SCREW CAP TO BRACKET
999
SCREW , Replaced By: N000000001146
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING
999
CROSS FITTING
999
NUT SUCTION LINE TO OIL PUMP
999
FITTING , Replaced By: A0019972372
999
FITTING CONNECTION "2"
999
SCREW PIPE CLAMP
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
SCREW BRACKET TO TRANSMISSION
999
CLAMP LINE CONNECTION
999
CLAMPTO 005 420 99 18
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
