Поз.
Артикул
Описание
107
BRACKET RIGHT
107
BRACKET LEFT
113
SCREW BRACKET TO SIDE MEMBER
113
SCREW , Replaced By: N304017010002
116
NUT STRAP TO BRACKET
116
NUT , Replaced By: N910113010000
158
BRACKET MUD APRON
161
SCREW COVER PLATE TO BRACKET
161
SCREW COVER PLATE TO BRACKET
164
NUT PUMP TO BRACKET
164
NUT , Replaced By: N913004006001
209
SHIM FRAME,5 506056
209
SHIM AUXILIARY FRAME MOUNTING
212
SCREW CONTROL ARM ON INTERMEDIATE PLATE M 20X205
212
SCREW AUXILIARY FRAME TO FRAME M 14X360
212
SCREW TORSION BAR TO SHACKLE,5 903514
212
SCREW ,5 903514, Replaced By: N000960012353
215
WASHER AUXILIARY FRAME
218
LOCK WASHER SUPPORT TO SIDE MEMBER, 10/20 UP TO IDENT NO. 4 399151,50/60 UP TO IDENT NO. 4 416112
221
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
352
SHACKLE AUXILIARY FRAME MOUNTING
355
SCREW CAB SUSPENSION,FRONT M 16X115
358
CONSOLE AUXILIARY FRAME MOUNTING
361
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
361
SCREW , Replaced By: N308676012026
361
SCREW CONSOLE TO SIDE MEMBER
361
SCREW
361
SCREW MOUNTING TO CONSOLE M 14X35
361
SCREW , Replaced By: N308676014008
361
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
361
SCREW , Replaced By: N308676014020
364
WASHER
364
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
364
WASHER , Replaced By: N000125015019
367
LOCK WASHER FITTING TO BRACKET
370
NUT SUPPORT TO SIDE MEMBER
370
NUT BRACKET TO SIDE MEMBER
370
NUT , Replaced By: N910113014001
373
NUT STRAP TO SUPPORT
376
SUPPORT RIGHT
376
SUPPORT LEFT
379
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
379
SCREW REAR EXHAUST PIPE TO MUFFLER
382
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
385
NUT
385
NUT , Replaced By: N304032010002
388
SCREW MOUNTING TO CAB
388
SCREW MOUNTING TO CAB
388
SCREW MOUNTING TO CAB
391
WASHER SPARE WHEEL CARRIER
391
WASHER SPARE WHEEL CARRIER
391
WASHER SPARE WHEEL CARRIER
391
WASHER SPARE WHEEL CARRIER
394
DISC SPRING CLAMP TO FRAME,5 521212
394
DISC SPRING CLAMP TO FRAME,5 521212
394
DISC SPRING CLAMP TO FRAME,5 521212
394
DISC SPRING CLAMP TO FRAME,5 521212
397
NUT COMBINATION CYLINDER TO BEARING BRACKET
397
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
397
NUT STEERING SUPPORT TO FRAME
397
NUT , Replaced By: N910113014000
397
NUT BRACKET TO SIDE MEMBER
397
NUT , Replaced By: N910113014001
400
SCREW RUBBER MOUNTING TO SUPPORTING ARM M16X80,5 566418
403
WASHER TORSION BAR TO BEARING BRACKET
403
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
416
SHACKLE AUXILIARY FRAME MOUNTING
419
SHACKLE AUXILIARY FRAME MOUNTING
425
SCREW AUXILIARY FRAME MOUNTING
425
SCREW AUXILIARY FRAME MOUNTING
425
SCREW CLAMP TO FRAME,5 506056
428
NUT CROSS MEMBER TO REINFORCEMENT
428
NUT , Replaced By: N913004020003
428
NUT SUPPORTING ARM TO FRONT RUBBER MOUNTING, 156152
437
PLATE AUXILIARY FRAME MOUNTING
437
PLATE AUXILIARY FRAME MOUNTING
437
PLATE AUXILIARY FRAME MOUNTING
440
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
440
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
440
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X60
440
SCREW STEERING SUPPORT TO FRAME M 14X50
440
SCREW REAR SPRING REAR BRACKET AND STRUT TO SIDE MEMBER
440
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
443
WASHER SPARE WHEEL CARRIER
446
NUT BRACKET TO SIDE MEMBER
446
NUT , Replaced By: N910113014001
446
NUT STEERING SUPPORT TO FRAME
446
NUT , Replaced By: N910113014000
449
CONSOLE , Replaced By: A3438910431
461
CONSOLE FRAME
464
CONSOLE AUXILIARY FRAME MOUNTING, FROM CHASSIS 4 409632 ALSO INSTALLED ON 540855-599999
467
LOCK WASHERROCKINGER TYP 59 G140,59 G150
467
LOCK WASHERROCKINGER TYP 59 G140,59 G150
470
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
470
NUT , Replaced By: N308673016001
477
CONSOLE FRAME
480
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
480
SCREW , Replaced By: N308676012011
480
SCREW , Replaced By: N308676012031
480
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
480
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
480
SCREW , Replaced By: N308676012026
480
SCREW CONSOLE TO SIDE MEMBER
480
SCREW CONSOLE TO SIDE MEMBER
483
LOCK WASHER CONSOLE TO FRAME AND TO AUXILIARY FRAME,RESP.
483
LOCK WASHER CONSOLE TO FRAME AND TO AUXILIARY FRAME,RESP.
486
NUT STRAP TO SUPPORT
486
NUT STRAP TO SUPPORT
492
BRACKET OIL LINE MOUNTING
495
SCREW PIPE CLAMP
495
SCREW , Replaced By: N304017008021
498
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
498
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
498
NUT , Replaced By: N913004008001
501
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
501
SCREW , Replaced By: N000960016206
504
NUT SUPPORT TO SIDE MEMBER
507
PLATE AUXILIARY FRAME MOUNTING, FROM CHASSIS 4 409632 ALSO INSTALLED ON 540855-599999
510
SHIM MOUNTING TO CONSOLE
513
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
513
HEXAGON HEAD BOLT. SCREW TRAILER COUPLING TO REAR CROSS MEMBER,5 734466
513
SCREW , Replaced By: N308765016010
516
NUT CONSOLE TO SUPPORT
516
NUT , Replaced By: N910113016001
520
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
520
HEXAGON HEAD BOLT. SCREW TRAILER COUPLING TO REAR CROSS MEMBER,5 734466
520
SCREW , Replaced By: N308765016010
520
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
520
SCREW BRACKET TO CAB CONSOLE,K 035197
520
SCREW BRACKET TO SIDE MEMBER
520
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
520
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X60
520
SCREW THRUST ARM TO SPRING BRACKET
520
SCREW STRUT TO SIDE MEMBER M 12X55
520
SCREW , Replaced By: N000960012384
520
SCREW RUBBER MOUNTING TO SUPPORTING ARM M16X80,5 566418
520
SCREW BRACKET TO CAB CONSOLE,K 035197
520
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
520
SCREW , Replaced By: N308676014020
520
SCREW BRACKET TO SIDE MEMBER
520
SCREW , Replaced By: N000961014064
520
SCREW , Replaced By: N308676012015
520
SCREW BRACKET TO FRAME,4 439997
523
WASHER TORSION BAR TO BEARING BRACKET
523
WASHER TORSION BAR TO BEARING BRACKET
523
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
523
WASHER SPARE WHEEL CARRIER
523
WASHER BEARING BRACKET TO FRAME
526
LOCK WASHERROCKINGER TYP 59 G140,59 G150
526
LOCK WASHER FITTING TO BRACKET
528
SHIM MOUNTING TO CONSOLE
529
NUT CONSOLE TO SUPPORT
529
NUT , Replaced By: N910113016001
529
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
529
NUT , Replaced By: N308673016001
529
NUT COMBINATION CYLINDER TO BEARING BRACKET
529
NUT COMBINATION CYLINDER TO BEARING BRACKET
529
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
529
NUT STRAP TO SUPPORT
529
NUT BRACKET TO SIDE MEMBER
529
NUT , Replaced By: N910113014001
529
NUT BRACKET TO SIDE MEMBER
999
CLAMP AUXILIARY FRAME 335 MM
999
GUIDE , Replaced By: A3436470021
999
BRACKET MUD APRON
999
BRACKET , Replaced By: A3525422840
999
PIPE CLAMP BRACKET TO CONSOLE
999
BRACKET LINE TO SUBSTRUCTURE
999
BASE , Replaced By: A3878910498
999
PLATE AUXILIARY FRAME MOUNTING, NOT USED
999
SCREW AUXILIARY FRAME MOUNTING
