Поз.
Артикул
Описание
348
PIPE , Replaced By: A3872950313
348
PIPE WITH BEAD, MASTER CYLINDER COUPLING TO EXPANSION RESERVOIR 10X700 MM
348
PIPE WITH BEAD, MASTER CYLINDER COUPLING TO EXPANSION RESERVOIR 10X700 MM
348
PIPE WITH BEAD, MASTER CYLINDER COUPLING TO EXPANSION RESERVOIR, 415 5 014668 416 5 000515 417 4 972023
356
PIPE , Replaced By: A3872950413
356
PIPE , Replaced By: A3872950413
356
PIPE FROM BRAKE MASTER CYLINDER TO RESERVOIR 550 MM, 415 5 014668 416 5 000515 417 4 972023
360
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
364
GROMMET CLUTCH LINE THRU CAB WINDOW SILL
364
GROMMET CLUTCH LINE THRU CAB WINDOW SILL,4 797364
366
GROMMET CLUTCH LINE THRU CAB WINDOW SILL,4 797365
368
GROMMET , Replaced By: A3819970581
368
GROMMET BRAKE LINE THRU CAB WINDOW SILL, 415 5 014668 416 5 000515 417 4 972023
372
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
372
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
376
WASHER COMPRESSED AIR LINE TO BRACKET
376
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
380
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
384
CLAMP LINE MOUNTING
388
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
392
NUT PUMP TO BRACKET
392
NUT , Replaced By: N913004006001
396
BRACKET HYDRAULIC LINE TO CAB, 415 5 014668 416 5 000515 417 4 972023
400
BRACKET HYDRAULIC LINE TO CAB, 415 5 014668 416 5 000515 417 4 972023
404
WASHER COMPRESSED AIR LINE TO BRACKET
404
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
408
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
412
CLAMP HYDRAULIC LINE TO BRACKET
416
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
420
NUT PUMP TO BRACKET
420
NUT , Replaced By: N913004006001
424
BRACKET BRAKE AND CLUTCH LINES, 415 5 014668 416 5 000515 417 4 972023
428
SCREW CONSOLE TO SIDE MEMBER
432
NUT SUPPORT TO SIDE MEMBER
436
BRACKET BRAKE AND CLUTCH LINES, 415 5 014668 416 5 000515 417 4 972023
440
SCREW BRACKET TO CROSS CONNECTION STRUT
440
SCREW , Replaced By: N304017008034
444
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
444
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
444
NUT , Replaced By: N913004008001
456
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
456
CLAMP ,K 147121, Replaced By: N000000000319
456
CLAMP , Replaced By: N916016008200
456
CLAMP , Replaced By: A3604300143
460
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
464
NUT PUMP TO BRACKET
464
NUT , Replaced By: N913004006001
468
LINE FROM VALVE TO CONNECTION FITTING,K 172343
468
LINE , Replaced By: A3812903214
468
LINE , Replaced By: A3812901714
468
LINE , Replaced By: A3812901714
472
GROMMET BATTERY CASE
472
GROMMET , Replaced By: A3149970581
476
LINE FROM ENGINE-MOUNTING BRACKET TO CLUTCH BOOSTER 550 MM, TO BE ADAPTED DURING ASSEMBLY
476
LINE , Replaced By: A3812901614
480
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 700 MM
480
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 700 MM
480
LINE , Replaced By: A3812901814
480
LINE , Replaced By: A3812900913
480
LINE , Replaced By: A3812901814
480
LINE , Replaced By: A3812901814
480
LINE , Replaced By: A3812900913
480
LINE HYDRAULIC HOSE TOWARDS CLUTCH BOOSTER 800 MM,5 401291 TO BE ADAPTED DURING ASSEMBLY
480
LINE , Replaced By: A3812901914
480
LINE , Replaced By: A3812901914
484
GROMMET TEMPERATURE GAUGE SENDER UNIT
488
HOSE FROM BRACKET UNDER CAB FLOOR TO OIL TANK BRACKET 555 MM
488
HOSE FROM BRACKET UNDER CAB FLOOR TO OIL TANK BRACKET 555 MM
492
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 350 MM
492
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 350 MM
492
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 215 MM
494
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER 350 MM, 024,026,027,028,121,122 5 095725 065,131,132 5 104253
496
BRACKET HYDRAULIC LINE, 415 5 014668 416 5 000515 417 4 972023
498
BRACKET HYDRAULIC LINE TO CAB FLOOR
500
SCREW PUMP TO BRACKET
500
SCREW , Replaced By: N304017006016
504
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
508
BRACKET LINES TO BRACKET
512
BRACKET LINES TO BRACKET
514
BRACKET OIL TANK
516
SCREW CLAMP MOUNTING M 6X16
516
SCREW , Replaced By: N000000001146
520
NUT PUMP TO BRACKET
520
NUT , Replaced By: N913004006001
524
LINE FROM FAN SHROUD BRACKET TO FITTING 2500 MM
524
LINE FROM FAN SHROUD BRACKET TO FITTING 2500 MM
524
LINE , Replaced By: A3812902314
524
LINE , Replaced By: A3812902314
524
LINE FROM SHUTTLE VALVE TO CLUTCH REMOTE CONTROL MASTER CYLINDER 1100 MM, TO BE ADAPTED DURING ASSEMBLY
524
LINE FROM SHUTTLE VALVE TO CLUTCH REMOTE CONTROL MASTER CYLINDER 1100 MM, TO BE ADAPTED DURING ASSEMBLY
524
LINE , Replaced By: A3812902713
528
LINE FROM SHUTTLE VALVE TO CLUTCH REMOTE CONTROL MASTER CYLINDER 1100 MM, TO BE ADAPTED DURING ASSEMBLY
528
LINE , Replaced By: A3812902014
528
LINE , Replaced By: A3812901514
529
LINE HYDRAULIC HOSE TOWARDS CLUTCH BOOSTER 800 MM,5 401291 TO BE ADAPTED DURING ASSEMBLY
529
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 700 MM
532
LINE FROM HYDRAULIC LINE TO CONNECTION FITTING 2000 MM, NOT USED
532
LINE FROM HYDRAULIC LINE TO CONNECTION FITTING 2000 MM, NOT USED
532
LINE FROM HYDRAULIC LINE TO CONNECTION FITTING 2000 MM, NOT USED
532
LINE , Replaced By: A3812902214
532
LINE , Replaced By: A3812902513
532
LINE , Replaced By: A3812902513
532
LINE , Replaced By: A3812902513
532
LINE , Replaced By: A3812902214
536
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
536
BRACKET. LOCK , Replaced By: A6525040038
540
INTERMEDIATE PIECE CLUTCH HOSE,K 172342
544
LINE FROM FITTING TO CLUTCH BOOSTER 3000 MM
544
LINE , Replaced By: A3812902414
544
LINE , Replaced By: A3812902414
544
LINE , Replaced By: A3812902414
544
LINE , Replaced By: A3812902414
547
ANGLE LINE MOUNTING
547
ANGLE LINE MOUNTING
549
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
549
SCREW , Replaced By: N304017008027
550
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
550
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
550
NUT , Replaced By: N913004008001
554
BRACKET CLUTCH HOSE TO FENDER BRACKET
554
BRACKET CLUTCH HOSE TO FENDER BRACKET
556
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
560
NUT STRAP TO BRACKET
560
NUT , Replaced By: N910113010000
564
BRACKET AT ENGINE MOUNTING CONSOLE
567
BRACKET HYDRAULIC LINE TO ENGINE MOUNTING
999
BOOTTO 001 295 30 06
999
LOCK RING LINE CONNECTION
999
LOCK LINE CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
GASKET KIT 3/2-WAY VALVE
999
SPACER TUBE BEARING BRACKET TO STEERING COLUMN BRACKET
999
ROD OVER-CENTER ACTING SPRING
999
ROD OVER-CENTER ACTING SPRING
999
PIN PUSH ROD TO PEDAL
999
WASHER BEARING BRACKET TO STEERING COLUMN BRACKET
999
BRACKET HYDRAULIC HOSE TO TRANSMISSION,5 213167
999
BRACKET BRACKET TO FAN SHROUD BRACKET
999
BRACKET 3/2-WAY VALVE, UP TO IDENT NO.5 238024,FROM IDENT NO. SEE GROUP 29
999
BRACKET HYDRAULIC LINE TO TRANSMISSION,5 309561
999
BRACKET PEDAL BEARING BRACKET
999
BRACKET 3/2-WAY VALVE TO PEDAL BEARING BRACKET
999
BRACKET BRACKET TO ENGINE,5 401291
999
BRACKET FUEL LINES TO TRANSMISSION
999
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
SCREW , Replaced By: N304017006020
999
SCREW COVER PLATE TO BRACKET
999
SCREW BRACKET ON LOAD SENSOR
999
SCREW , Replaced By: N304017008021
999
NUT BALL PIVOT TO LEVER
999
WASHER VALVE TO BRACKET
999
NUT SUCTION LINE TO OIL PUMP
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW PIPE CLAMP
999
SCREWM 16X25
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
