Поз.
Артикул
Описание
172
PLASTIC PIPE RISING PIPE 4X6 MM
172
PLASTIC PIPE RISING PIPE 4X6 MM
172
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
173
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
267
AIR CLEANERWABCO
267
AIR CLEANERKNORR
267
AIR CLEANERBOSCH
268
AIR CLEANERGRAU
272
FITTING AIR RESERVOIR,CONNECTION: "13"
274
O-RING CHECK VALVE TO AIR RESERVOIR
275
THRUST RING CHECK VALVE TO AIR RESERVOIR
276
NUT CHECK VALVE TO AIR RESERVOIR
360
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
360
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
360
SCREW BRACKET TO SIDE MEMBER
360
SCREW , Replaced By: N304017008040
361
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
361
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
361
NUT , Replaced By: N913004008001
371
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
384
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
386
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
388
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
390
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
VALVETO 003 429 04 44,WABCO
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
PROTECTIVE CAPTO 008 420 62 18,KNORR
999
VALVE TAPPETTO 002 429 96 44,VOSS
999
FILTER ELEMENTTO 000 429 28 95,GRAU
999
FILTER ELEMENT MAJOR TO 000 429 27 95,WABCO
999
THRUST RING SUCTION LINE TO OIL PUMP
999
FILTER ELEMENT MINOR TO 000 429 27 95,WABCO
999
THRUST WASHERTO 003 429 12 44,SCHAEFER
999
SEAL CONETO 003 429 12 44,SCHAEFER
999
FILTER ELEMENTTO 000 429 25 95,BOSCH
999
DIAPHRAGMTO 000 429 28 95,GRAU
999
DIAPHRAGMTO 000 429 25 95,BOSCH
999
SEAL RINGTO 002 429 96 44,VOSS
999
ADAPTER FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22"
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KIT PRESSURE REGULATOR BOSCH,241
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KITTO 000 430 56 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE HAND BRAKE VALVE KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KIT SEAL RING BOSCH,209
999
DIAPHRAGM , Replaced By: A0004314128
999
DIAPHRAGM , Replaced By: A0004314128
999
GASKET34X2X6 MM,GRAU
999
TEST CONNECTION
999
VALVE SEATGRAU
999
VALVE
999
VALVEWABCO
999
DIAPHRAGMTO 008 420 61 18,009 420 22 18
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
REPAIR KIT , Replaced By: A0004305860
999
SEALING CORDTO 000 429 27 95, WABCO
999
SEALING CORD SUCTION LINE TO OIL PUMP
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
CONNECTOR REPAIR SIZE
999
SPRING , Replaced By: A0009935205
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK ELECTRIC CABLE THRU CAB FLOOR
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLEKNORR
999
PLUGTO 009 420 22 18,008 420 20 18
999
PLUG
999
VALVE , Replaced By: A0034291644
999
VALVE (RELAY VALVE) WABCO
999
VALVE PARKING BRAKE VALVE BOSCH
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PROTECTIVE CAPTO WABCO
999
CUPTO 002 431 04 06,BOSCH
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPKNORR
999
REPAIR KIT COVERING BOSCH
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
SEALING CORD38X8 MM
999
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
SEAL RINGTO 000 429 25 95,BOSCH
999
VALVE , Replaced By: A0034295344
999
VALVE (CHECK VALVE) VOSS
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
VALVE PARKING BRAKE VALVE KNORR
999
PRESSURE REGULATOR , Replaced By: A0024314306
999
PRESSURE REGULATOR WITH TIRE INFLATING CONNECTION BOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18, UP TO SCHAEFER CHARACTERISTIC NO.489
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18
999
REPAIR KITGRAU,5 148812
999
REPAIR KITTO BOSCH
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 433281
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
VALVE (CHECK VALVE) WABCO
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
REPAIR KITTO 001 430 56 81,001 430 57 81
999
PRESSURE REGULATORBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
FITTING , Replaced By: A0029905971
999
SEAL RINGBOSCH
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SPRINGTO 000 429 27 95,WABCO
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RING34.6X2.6 MM
999
SEAL RING19.3X2.4 MM,TO 003 429 04 44,WABCO
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING28.4X2.6 MM
999
SEAL RING56X1.7 MM
999
SEAL RINGKNORR
999
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RINGTO 001 431 43 05
999
SEAL RING , Replaced By: A0049970248
999
SEAL RINGTO 000 429 25 95,BOSCH
999
SEAL RINGTO 000 429 27 95, WABCO
999
ELBOW FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
WASHER BRACKET TO CROSS MEMBER,5 434013
999
ANGLE LINE MOUNTING
999
BRACKET BUMPER,RIGHT, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BRACKET PRESSURE GAUGE LINE TO BRACKET,4 895864
999
ADHESIVE FOIL GUIDE SIGN
999
BRACKET HEAT SHIELD
999
BRACKET RIGHT COMPRESSED AIR LINES
999
BRACKET , Replaced By: A6154200186
999
SEAL RING TO SEAL CABLE HARNESS OPENING IN CAB
999
LOCK BRAKE HOSE TO ANGLE
999
BRACKET FOR PASSAGE OF LINE
999
BRACKET , Replaced By: A6164290140
999
STRAP AIR RESERVOIR TO BRACKET
999
STRAP ANTI-FREEZE DEVICE
999
COVERING CHECK VALVE,5 298639
999
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
999
BRACKET REGULATING VALVE
999
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
COTTER PIN STRAP TO SUPPORT
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER BRACKET TO FRAME
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW , Replaced By: N304017008039
999
SCREW , Replaced By: N304017008027
999
SCREW HAND PUMP TO BRACKET
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING LINE CONNECTION
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
999
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT PUMP TO BRACKET
999
UNION NUT LINE CONNECTION
999
HOLLOW SCREW HEATING CONNECTION
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
HOLLOW SCREW , Replaced By: N915036010108
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
