Поз.
Артикул
Описание
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
154
TEST CONNECTION
154
TEST CONNECTION
154
TEST CONNECTION
154
TEST CONNECTION
196
VALVE (PRESSURE LIMIT VALVE)
199
REPAIR KIT PRESSURE LIMIT VALVE
202
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
205
T-FITTING CHECK VALVE TO RELAY VALVE
208
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
208
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
211
THRUST RING CHECK VALVE TO AIR RESERVOIR
211
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
214
O-RING CHECK VALVE TO AIR RESERVOIR
217
NUT CHECK VALVE TO AIR RESERVOIR
220
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
220
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
220
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
220
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
223
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
223
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
223
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
223
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
226
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
226
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
226
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
229
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
229
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
229
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
232
VALVE (OVERFLOW VALVE) WABCO
232
VALVE , Replaced By: A0044293144
232
VALVE , Replaced By: A0044293144
232
VALVE (OVERFLOW VALVE) GRAU
232
VALVE , Replaced By: A0044293244
232
VALVE , Replaced By: A0044293244
232
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0034290844
232
VALVE (OVERFLOW VALVE) WABCO
232
VALVE , Replaced By: A0044293144
232
VALVE , Replaced By: A0034290944
235
VALVE
238
DIAPHRAGM
241
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
241
REPAIR KITTO 001 429 52 44
244
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
247
NUT CHECK VALVE TO AIR RESERVOIR
247
NUT CHECK VALVE TO AIR RESERVOIR
250
FITTING SHUTTLE VALVE,CONNECTION: "20"
253
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
253
ELBOW FITTING , Replaced By: A0004294638
259
THRUST RING CHECK VALVE TO AIR RESERVOIR
259
THRUST RING CHECK VALVE TO AIR RESERVOIR
259
THRUST RING CHECK VALVE TO AIR RESERVOIR
259
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
262
O-RING CHECK VALVE TO AIR RESERVOIR
262
O-RING CHECK VALVE TO AIR RESERVOIR
262
O-RING CHECK VALVE TO AIR RESERVOIR
265
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
265
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
268
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
271
RESERVOIR20L,246 MM,12.5 BAR
271
RESERVOIR , Replaced By: A0034321201
271
RESERVOIR , Replaced By: A0014327501
271
RESERVOIR COMPRESSED AIR,5 295503
271
RESERVOIR , Replaced By: A0034321201
277
BRACKET AIR RESERVOIR TO FRAME
289
STRAP AIR RESERVOIR TO BRACKET
295
SCREW PIPE CLAMP
295
SCREW , Replaced By: N304017008021
298
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
298
NUT , Replaced By: N913004008001
301
NUT STRAP TO BRACKET
301
NUT , Replaced By: N910113010000
304
FITTING SHUTTLE VALVE,CONNECTION: "20"
307
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
307
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
313
THRUST RING CHECK VALVE TO AIR RESERVOIR
313
THRUST RING CHECK VALVE TO AIR RESERVOIR
313
THRUST RING CHECK VALVE TO AIR RESERVOIR
313
THRUST RING CHECK VALVE TO AIR RESERVOIR
313
THRUST RING CHECK VALVE TO AIR RESERVOIR
313
THRUST RING CHECK VALVE TO AIR RESERVOIR
313
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
316
O-RING CHECK VALVE TO AIR RESERVOIR
316
O-RING CHECK VALVE TO AIR RESERVOIR
316
O-RING CHECK VALVE TO AIR RESERVOIR
316
O-RING CHECK VALVE TO AIR RESERVOIR
316
O-RING CHECK VALVE TO AIR RESERVOIR
316
O-RING CHECK VALVE TO AIR RESERVOIR
331
VALVE. DRAIN VALVE DRAIN
331
VALVE DRAIN, Replaced By: A0004322107
331
VALVE DRAIN, Replaced By: A0004322407
331
VALVE. DRAIN VALVE DRAIN
331
VALVE DRAIN, Replaced By: A0004322107
334
O-RING CHECK VALVE TO AIR RESERVOIR
337
THRUST RING CHECK VALVE TO AIR RESERVOIR
337
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
999
AIR CLEANER COMPLETE TO BOSCH,KNORR
999
STRAINERTO 000 434 21 01
999
CUP 3/2-WAY VALVE WABCO
999
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
999
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
999
HANDLETO 000 434 23 01
999
COUPLING FROM CHECK VALVE TO PARKING BRAKE VALVE
999
PLUG
999
GASKET KITKNORR
999
SPRINGTO 000 434 21 01
999
REPAIR KITBOSCH
999
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
REPAIR KIT 3/2-WAY VALVE BOSCH
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
SEAL RINGTO 000 434 21 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGWABCO
999
SCREW EXHAUST PIPE TO BRACKET
999
BRACKET SPRING-LOADED BRAKE AIR RESERVOIR
999
STRAP SPRING-LOADED BRAKE AIR RESERVOIR, Replaced By: A6554900942
999
STRAP , Replaced By: A6214900242
999
STRAP , Replaced By: A6554900942
999
STRAP PARTICLE FILTER
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW , Replaced By: A4609900601
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SEAL RING LINE CONNECTION
999
SEAL RING LINE CONNECTION
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
HOLLOW SCREW HEATING CONNECTION
999
HOLLOW SCREW FITTING DIAPHRAGM CYLINDER,CONNECTION: "12"
999
HOLLOW SCREW LINE CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
