Поз.
Артикул
Описание
348
JOINT , Replaced By: A0009965245
348
ARTICULATION PIECE LEVER TO SUPPORT
352
REPAIR KIT JOINT
356
ARTICULATION PIECE , Replaced By: A0009965045
356
ARTICULATION PIECE , Replaced By: A0009965545
356
ARTICULATION PIECE R.H. THREAD, Replaced By: A0019963045
356
CONSTANT VELOCITY JOINT R.H. THREAD
360
ARTICULATION PIECE , Replaced By: A0009965145
360
ARTICULATION PIECE , Replaced By: A0009965645
360
ARTICULATION PIECE L.H. THREAD, Replaced By: A0019963145
360
CONSTANT VELOCITY JOINT L.H. THREAD
372
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
376
SHIFTING ROD , Replaced By: N900331012338
376
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLYK 142858
396
SCREW , Replaced By: N304017010002
396
SCREW BRACKET TO SIDE MEMBER
396
SCREW BRACKET TO SIDE MEMBER
416
NUT PULL ROD
420
NUT STRAP TO SUPPORT,5 149419
424
NUT , Replaced By: N910113010000
424
NUT STRAP TO BRACKET
428
NUT JOINT TO LEVER
432
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
436
NUT , Replaced By: N308675014001
436
NUT JOINT TO BRACKET
464
BRACKET TRANSMISSION GEARSHIFT
468
BRACKET TRANSMISSION GEARSHIFT
472
BRACKET TRANSMISSION GEARSHIFT
476
BRACKET TRANSMISSION GEARSHIFT
480
LEVER TRANSMISSION GEARSHIFT
484
LEVER TRANSMISSION GEARSHIFT
488
CLAMPING PIECE TRANSMISSION GEARSHIFT
492
SCREW SUPPORT TO CROSS MEMBER M 10X28
496
NUT , Replaced By: N910113010000
496
NUT STRAP TO BRACKET
500
SCREW BRACKET TO TIMING CASE
504
SCREW , Replaced By: N304017008040
504
SCREW BRACKET TO SIDE MEMBER
508
SPRING WASHER BRACKET TO TIMING CASE
512
SPRING WASHER , Replaced By: N000137008212
512
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
516
SCREW , Replaced By: N304017008034
516
SCREW BRACKET TO CROSS CONNECTION STRUT
520
NUT , Replaced By: N913004008001
520
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
524
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
528
ROUND CORD RING. SEAL RING ROD END
532
SCREW , Replaced By: N000933010192
532
SCREW SHIFTING ROD TO SHIFT LEVER
536
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
540
NUT , Replaced By: N910113010000
540
NUT STRAP TO BRACKET
604
COVERING BOTTOM
608
COVERING TOP
612
BRACKET , Replaced By: A3874296740
612
BRACKET 3/2-WAY VALVE,5 198435
999
BRACKET OIL LINE
999
BUSHING PAWL TO ROD END,5 443048
999
COVERING GEARSHIFT MECHANISM
