Поз.
Артикул
Описание
56
PLASTIC PIPE RISING PIPE 4X6 MM
56
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
64
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
72
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
80
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
88
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
96
FITTING , Replaced By: A0029905971
96
FITTING (PARTS KIT),LINE RUPTURE
104
UNION NUT LINE CONNECTION
112
GLAND LINE CONNECTION
120
SLEEVE LINE CONNECTION
128
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
408
VALVE (3/2-WAY SOLENOID VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
416
BRACKET SOLENOID VALVE
424
SCREW VALVE TO BRACKET M 8X55
424
SCREW , Replaced By: N304017008043
432
NUT , Replaced By: N913004008001
432
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
440
BREATHER , Replaced By: A3933280065
440
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
440
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
448
REINFORCEMENT DISTRIBUTOR TO CAB
456
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
464
HOLLOW SCREW LINE CONNECTION
472
SEAL RING LINE CONNECTION
999
TEST CONNECTION
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
SEAL RINGWABCO
999
BRACKET DIAPHRAGM CYLINDER,5 434013
999
COVERING 2/2-WAY VALVE
999
SCREW AT SIDE MEMBER,REAR M 8X135
999
SCREW , Replaced By: N304017008034
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
HOLLOW SCREW HEATING CONNECTION
999
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
