Поз.
Артикул
Описание
6
BRACKET
6
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.019394, Replaced By: A6314601035
6
BRACKET , Replaced By: A6314601235
9
RIVET
12
OIL TANK , Replaced By: A6314600183
12
OIL TANK ,019394
15
OIL TANK , 806686 P000001
18
SCREW , FOR USE WITH POWER STEERING019394
21
LOCK ,019394
24
FILTER , FOR USE WITH POWER STEERING019394
27
COVER , FOR USE WITH POWER STEERING019394
30
SPRING , FOR USE WITH POWER STEERING019394
33
SEAL RING , FOR USE WITH POWER STEERING019394
36
WASHERTO 309 460 03 83
45
NUTTO 631 460 00 83
48
FILLER CAP ,019394
51
FILTER
54
SEAL RING
57
OIL DIPSTICK
60
PROTECTIVE CAP
63
LOOM TIE TANK TO BRACKET
63
CLAMP , Replaced By: A0059972990
63
LOOM TIE TANK TO BRACKET
63
CLAMP , Replaced By: N000000000675
63
CLAMP TANK TO BRACKET
66
CONNECTOR DELIVERY LINE TO PUMP, FOR USE WITH POWER STEERING UP TO IDENT NO. 083195 EXCEPT FOR 082032,082039,082089,082254,083149,083152,083155,091959.
69
WASHER DELIVERY LINE TO PUMP
72
SEAL RING DELIVERY LINE TO PUMP
75
HOSEKP:DUO 434/02
75
HOSE FROM STEERING TO OIL TANK, FROM IDENT NO. 083196 ALSO INSTALLED ON 082032,082039,082089,082254,083149,083152,083155,091959.
75
HOSE FROM STEERING TO OIL TANK,019394
78
LOOM TIE , Replaced By: A6319974390
78
LOOM TIE HOSE TO OIL TANK, UP TO IDENT NO. 083195 EXCEPT FOR 082032,082039,082089,082254,083149,083152,083155,091959.
78
CLAMP LINE MOUNTING
81
CONNECTOR LINE TO STEERING, UP TO IDENT NO. 083195 EXCEPT FOR 082032,082039,082089,082254,083149,083152,083155,091959.
84
WASHER LINE TO STEERING, FOR USE WITH POWER STEERING
87
SEAL RING LINE TO STEERING, FOR USE WITH POWER STEERING
90
CONNECTOR LINE TO STEERING, UP TO IDENT NO. 083195 EXCEPT FOR 082032,082039,082089,082254,083149,083152,083155,091959.
93
CLAMP LINE MOUNTING
93
LOOM TIE , Replaced By: A6319974490
93
LOOM TIE DELIVERY LINE TO PUMP
93
LOOM TIE
96
HOSE
96
HOSE FROM TANK TO HOSE,019394
99
CLAMP LINE MOUNTING
99
LOOM TIE , Replaced By: A6319974490
99
LOOM TIE
99
LOOM TIE DELIVERY LINE TO PUMP
102
LOOM TIE , FOR USE WITH POWER STEERING
102
LOOM TIE OIL LINES, FOR USE WITH POWER STEERING019395
102
LOOM TIE OIL LINES,019394
105
STOP
108
PIN OIL LINES, UP TO IDENT NO. 083195 EXCEPT FOR 082032,082039,082089,082254,083149,083152,083155,091959.
111
BANJO UNION
111
LINE , Replaced By: A6319900188
114
SEAL RING ON OIL PUMP HOUSING
117
HOLLOW SCREW , Replaced By: N915036015201
120
SCREW-IN FITTING DELIVERY LINE TO PUMP
120
FITTING DELIVERY LINE TO PUMP
123
LOOM TIE
123
CLAMP LINE MOUNTING
123
LOOM TIE DELIVERY LINE TO PUMP
126
HOSE FROM POWER STEERING PUMP TO STEERING, FROM IDENT NO. 083196 ALSO INSTALLED ON 082032,082039,082089,082254,083149,083152,083155,091959.
126
HOSE FROM POWER STEERING PUMP TO STEERING, UP TO IDENT NO. 083195 EXCEPT FOR 082032,082039,082089,082254,083149,083152,083155,091959.
129
CONNECTOR DELIVERY LINE TO STEERING, UP TO IDENT NO. 083195 EXCEPT FOR 082032,082039,082089,082254,083149,083152,083155,091959.
132
WASHER DELIVERY LINE TO STEERING, FOR USE WITH POWER STEERING
135
SEAL RING DELIVERY LINE TO STEERING, FOR USE WITH POWER STEERING
138
LOOM TIE
138
LOOM TIE
141
CLIP
144
SCREW PARTICLE FILTER
144
SCREW CONSOLE TO FRAME M 14X1.5X100
147
PITMAN ARM ,013478
147
PITMAN ARM
150
BOOT
150
BOOT , FROM IDENT NO. 083196 ALSO INSTALLED ON 082032,082039,082089,082254,083149,083152,083155,091959.
999
COVER
999
COVER
999
PITMAN ARM , NOT USED
