Поз.
Артикул
Описание
5
OIL TANK REFRIGERANT
6
VALVE
7
SEAL RING FROM EXPANSION VALVE TO COMPRESSOR
8
BRACKET LIQUID TANK
14
SCREW FROM THERMOSTAT TO RADIATOR
17
WASHER PLUG SOCKET TO BRACKET
23
LOOM TIE
23
CLAMP , Replaced By: N000000000673
23
CLAMP HOSE TO RETARDER 60-80X13 MM
29
PIPE LINE DRIER FOR EXPANSION VALVE
35
SEAL RING HOSE TO CONDENSER 14 MM
41
VALVE
44
CAP
47
PIPE LINE FROM EXPANSION VALVE SEPARATION POINT,016686
47
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR,016685
47
PIPE LINE FROM EXPANSION VALVE SEPARATION POINT
59
O-RING HOSE TO EXPANSION VALVE 17X2
59
SEAL RING
60
SEAL RING SEPARATION POINT TO 638 830 13 15
62
VALVE , NOT USED
65
CAP , NOT USED
74
PIPE LINE COMPRESSOR-TO-CONDENSER REFRIGERANT LINE,016686
80
RUBBER RING
83
SEAL RING HOSE TO CONDENSER 14 MM
86
SEAL RING FROM LIQUID TANK TO T-FITTING
95
PIPE LINE REFRIGERANT LINE TO CONDENSER,146177
95
PIPE LINE REFRIGERANT LINE TO CONDENSER,146178157783
96
PIPE LINETO 638 830 14 15
98
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
101
SENSOR AT LIQUID TANK
104
SEAL RING FROM EXPANSION VALVE TO COMPRESSOR
107
SWITCHTO 638 830 11 15
110
PLUG HOUSING 4-POLE
113
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
116
SWITCH AT LIQUID TANK,FOR ADDITIONAL BLOWER, F 140421 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM F 140422 WITH CODE 806
119
SEAL RING FROM EXPANSION VALVE TO COMPRESSOR
122
INSULATING SLEEVE CABLE HARNESS FOR ELECTRIC SEAT ADJUSTER
152
BRACKET PIPE LINE TO ENGINE
173
BRACKET PIPE LINE TO ENGINE,016686
176
CLAMP BRAKE HOSE BRACKET
179
SCREW FROM THERMOSTAT TO RADIATOR
182
WASHER PLUG SOCKET TO BRACKET
185
SCREW , Replaced By: A0099900101
185
SCREW , Replaced By: N000933008337
188
NUT
215
BRACKET BRACKET TO SUPPORT
218
CLAMP LINE MOUNTING SA 088202/01
221
CLAMP HOSE TO FLANGE AND TO VALVE
224
NUT
227
CLAMP LINE MOUNTING
230
SHEET METAL SCREW
233
LOOM TIE LINE MOUNTING 280 MM
999
PIPE LINE
999
PIPE LINE
999
PIPE LINE
