Mercedes N912004008102 - Кольцо стопорное

V 200 CDI, V 220 CDI, V 200, V 230, V 280 638.294 FROM IDENT-NR. 246706

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 070 BATTERY, MOUNTING, AND BATTERY CABLES IL. 2

Поз.
Артикул
Описание
41
A0019954301
CLAMP
44
N910143006001
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
44
N000000004310
HEXAGON HEAD BOLT LINE MOUNTING M6X10
62
N916016028204
CLAMP FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BRACKET
63
N910112006003
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
63
N304032008006
NUT
64
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
65
N913023006001
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
65
N000000003175
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
80
N000000003175
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
80
N910112005000
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
80
N910112006003
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
80
N913023008003
NUT HORN TO BRACKET M8
86
A9015460243
BRACKET AT CLUTCH BELL, P 503835 R 000001
95
A1031591140
BRACKET MICRO-SWITCH CABLE TO FUEL THERMOSTAT
98
N000000001114
HEXALOBULAR BOLT. SCREW BRACKET TO TRANSMISSION M 6X15
101
A6385460343
104
A6385460443
107
N910143010017
HEXALOBULAR BOLT BRACKET AND DISTRIBUTOR TO REAR AXLE I M 10X55
110
N910113010001
NUT CROSS MEMBER TO SIDE MEMBERS
