Поз.
Артикул
Описание
20
SUPPORT LEFT
20
SUPPORT LEFT
35
SUPPORT AT BRACKET
85
SCREW CONSOLE TO SIDE MEMBER
85
SCREW CONSOLE TO SIDE MEMBER
90
NUT SUPPORT TO SIDE MEMBER
115
SUPPORT RIGHT
120
SUPPORT AT BRACKET
130
BRACKET AT BRACKET
145
SCREW CONSOLE TO SIDE MEMBER
145
SCREW CONSOLE TO SIDE MEMBER
145
SCREW CONSOLE TO SIDE MEMBER
150
NUT SUPPORT TO SIDE MEMBER
150
NUT SUPPORT TO SIDE MEMBER
155
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
280
NUT BRACKET TO SIDE MEMBER
280
NUT BRACKET TO SIDE MEMBER
280
NUT BRACKET TO SIDE MEMBER
280
NUT , Replaced By: N910113014001
285
PLATE BRACKET TO FRAME
290
SPACER BRACKET TO FRAME
295
SCREW BRACKET TO CAB CONSOLE,K 035197
335
SCREW CONSOLE TO SIDE MEMBER
335
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
335
SCREW CONSOLE TO SIDE MEMBER
335
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
335
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
335
SCREW , Replaced By: N308676012026
335
SCREW CONSOLE TO SIDE MEMBER
340
NUT SUPPORT TO SIDE MEMBER
340
NUT SUPPORT TO SIDE MEMBER
340
NUT SUPPORT TO SIDE MEMBER
350
NUT SUPPORT TO SIDE MEMBER
355
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
355
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
355
SCREW , Replaced By: N308676012026
445
ANGLE
450
BEARING BRACKET
455
WEB SPARE WHEEL CARRIER
460
SCREW END PIECE TO EXHAUST PIPE M 10X25
462
WASHER RADIATOR TO RUBBER MOUNTING
462
WASHER , Replaced By: N000125010532
465
NUT STRAP TO BRACKET
465
NUT , Replaced By: N910113010000
999
CLAMP , Replaced By: A3874900041
999
CLAMP EXHAUST MUFFLER TO BRACKET
999
WASHER LEFT AND RIGHT CONSOLES TO FRAME
999
SPACER SPARE WHEEL TO SPARE WHEEL WINCH, ONLY FOR USE WITH SA 32220/05 TO BE ADAPTED DURING ASSEMBLY
