Поз.
Артикул
Описание
101
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
101
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
107
ROD END HYDRAULIC RELEASE
110
SEAL RING HYDRAULIC RELEASE
113
PAWL SHIFTING ROD,5 443048
113
PAWL ,5 4430475 443048, Replaced By: A6202600087, +001A6202680150
116
BUSHING PAWL TO ROD END,5 443047
116
BUSHING PAWL TO ROD END,5 443048
116
BUSHING PAWL TO ROD END,5 443048
119
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
122
ROUND CORD RING. SEAL RING ROD END
125
SPRING ROD END
128
SPRING ROD END
131
SCREW SHIFTING ROD TO SHIFT LEVER
131
SCREW , Replaced By: N000933010192
134
NUT , Replaced By: N910113010000
134
NUT STRAP TO BRACKET
137
SHIFTING TUBE (TELESCOPIC TUBE)
140
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
140
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
143
SEAL RING PISTON RINGS WABCO
146
SEAL RING SCREW FITTING WABCO
149
SEAL RING OUTSIDE WABCO
152
SPRING WASHER SHIFTING CYLINDER TO YOKE
155
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
158
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
161
COTTER PIN LEVER TO ROD
161
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
167
WASHER BETWEEN THE SHIFTING RODS
170
SHIFTING ROD REAR
176
SHIFTING ROD REAR
185
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
188
NUT , Replaced By: N910113010000
188
NUT STRAP TO BRACKET
191
SCREW CONNECTOR TO REAR SHIFTING ROD
197
JOINT SHIFTING ROD TO TRANSMISSION
197
JOINT SHIFTING ROD TO TRANSMISSION
206
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
206
CONNECTOR SHIFTING ROD TO TRANSMISSION
212
SCREW SHIFTING ROD TO TRANSMISSION
218
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
221
NUT
224
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
227
ROUND CORD RING. SEAL RING ROD END
230
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
233
SCREW SHIFTING ROD TO SHIFT LEVER
233
SCREW , Replaced By: N000933010192
236
NUT , Replaced By: N910113010000
236
NUT STRAP TO BRACKET
999
INSULATION CAB/TRANSMISSION COMPRESSED-AIR-LINE SEPARATION POINT
999
CONNECTOR REAR SHIFTING ROD TO CONNECTOR
999
INSULATION , Replaced By: A3816822544
999
PIN SHIFT LEVER BEARING,K 040604
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
EXPANSION PLUG ROD END
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
