Поз.
Артикул
Описание
96
CONNECTION FITTING ,880809
108
LINE FROM T-FITTING TO DOUBLE FITTING
108
LINE FROM FITTING TO AIR RESERVOIR
120
UNION NUT LINE CONNECTION
132
GLAND LINE CONNECTION
144
FITTING FITTING TO FIRE WALL, NOT USED
144
FITTING LINE CONNECTION TO FIRE WALL,684146
156
NUT ELECTRONIC ACCELERATOR PEDAL
168
WASHER
172
SPRING WASHER BRACKET TO BRACKET
176
TOOTHED WASHER LINE CONNECTION TO FIRE WALL,684146
180
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
192
UNION NUT LINE CONNECTION
204
GLAND LINE CONNECTION
216
SLEEVE LINE CONNECTION
228
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3454307481
228
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3454307481
228
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3454307481
240
REPAIR KIT , Replaced By: A0034301081
240
REPAIR KIT IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 000 586 23 43,
240
REPAIR KIT IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 000 586 23 43,
240
REPAIR KIT IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 000 586 23 43,
246
VALVE HAND BRAKE VALVE WABCO
246
VALVE HAND BRAKE VALVE WABCO
246
VALVE HAND BRAKE VALVE WABCO
246
VALVE HAND BRAKE VALVE WABCO
252
SCREW-IN FITTING LINE CONNECTION
252
SCREW-IN FITTING LINE CONNECTION
264
SEAL RING
264
SEAL RING
276
BRACKET HAND BRAKE VALVE
288
SCREW , Replaced By: N304017008027
288
SCREW COLD START SYSTEM TO BRACKET
300
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
312
NUT TAIL LAMP TO BRACKET
312
NUT , Replaced By: N304032008006
324
STEERING COLUMN BRACKET
324
STEERING COLUMN BRACKET
336
SCREW STEERING SHAFT BEARING TO CAB M 8X20
336
SCREWM 8X20
348
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
360
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
360
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
372
UNION NUT LINE CONNECTION
384
GLAND LINE CONNECTION
396
SLEEVE LINE CONNECTION
408
FITTING FITTING TO FIRE WALL, NOT USED
420
NUT ELECTRONIC ACCELERATOR PEDAL
432
WASHER
444
LINE FROM T-FITTING TO DOUBLE FITTING
444
LINE FROM DOUBLE FITTING I TO DOUBLE FITTING II
456
UNION NUT LINE CONNECTION
468
GLAND LINE CONNECTION
504
CONNECTION FITTING ,880809
600
BRACKET FUEL LINE
600
BRACKET FUEL LINES
612
BRACKET COMPRESSED AIR LINE MOUNTING
624
CLAMP , Replaced By: A3379950332
624
CLAMP
636
SCREW PROTECTION PLATE TO BRACKET
648
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
660
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
672
NUT BALL PIVOT TO LEVER
684
LOOM TIE , Replaced By: A0019978490
684
LOOM TIE LINE MOUNTING
999
SWITCH TWO-CIRCUIT BRAKE VALVE
999
CABLE HARNESS
999
CABLE HARNESS
999
CABLE HARNESS
999
PIN BUSHING HOUSING UNIPOLAR
999
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
HANDLETO 345 430 75 81
999
GROMMET3.0 MM
999
PINTO 345 430 75 81
999
SWITCH EXHAUST BRAKE,K 251255
999
PLUG SOCKETTO 341 540 82 10
999
VALVE , Replaced By: A0004291182
