Поз.
Артикул
Описание
10
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
20
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
20
CLAMP , Replaced By: N000000000667
30
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
30
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
30
LINE FROM OIL TANK TO HOSE
40
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
40
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
40
LINE , Replaced By: A0004291601
50
ELBOW FITTING SUCTION LINE TO OIL PUMP
60
THRUST RING SUCTION LINE TO OIL PUMP
70
SEALING CORD SUCTION LINE TO OIL PUMP
75
NUT SUCTION LINE TO OIL PUMP
80
FITTING SUCTION LINE TO OIL PUMP
90
FITTING DELIVERY LINE TO PUMP
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
100
LINE FROM PUMP TO HIGH PRESSURE HOSE
100
LINE FROM PUMP TO HIGH PRESSURE HOSE
105
TUBE FROM HIGH PRESSURE HOSE TO STEERING
105
LINE , Replaced By: A0005516156
110
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
110
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
110
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
110
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
110
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
110
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
120
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
120
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
120
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX
130
LINE RETURN, FROM STEERING TO OIL TANK
130
LINE RETURN, FROM STEERING TO OIL TANK
130
LINE RETURN, FROM STEERING TO OIL TANK
140
HOSE DELIVERY LINE TO STEERING
150
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
160
BRACKET DELIVERY AND SUCTION LINES TO FRAME
160
BRACKET DELIVERY AND SUCTION LINES TO FRAME
170
CLAMP DELIVERY AND SUCTION LINES TO STEERING
170
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
180
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
180
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
180
CLAMP LINE MOUNTING
