Поз.
Артикул
Описание
5
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
5
FITTING OIL LINE CONNECTION
5
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
5
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
8
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
8
FITTING AIR DEHYDRATOR
8
FITTING BULKHEAD FITTING
8
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
11
ADAPTER FITTING LINE CONNECTION TO ENGINE
14
BRACKET BATTERY CABLE TO ENGINE MOUNTING
17
BRACKET OIL LINE MOUNTING
17
BRACKET FUEL LINES TO TRANSMISSION
20
BRACKET LINE MOUNTING
23
ANGLE LINE MOUNTING
26
WASHER BRACKET TO LEFT SIDE MEMBER
29
BRACKET PULL ROD TO SUPPORT,5 352764 TO BE ADAPTED DURING ASSEMBLY
32
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
32
BRACKET FUEL LINE TO BELL HOUSING
35
CLAMP OIL DIPSTICK TO RADIATOR
35
CLAMP DELIVERY AND SUCTION LINES TO STEERING
35
CLAMP AT BRACKET
38
CLAMP LINE MOUNTING
41
GROMMET LINE MOUNTING
44
ELBOW FITTING , Replaced By: A0039901671
44
ELBOW FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20", Replaced By: A6209900071
47
T-FITTING LINE CONNECTION TO AIR COMPRESSOR
50
SEAL RING LINE CONNECTION
50
SEAL RING LINE CONNECTION
53
THRUST RING CHECK VALVE TO AIR RESERVOIR
53
THRUST RING SUCTION LINE TO OIL PUMP
53
O-RING CHECK VALVE TO AIR RESERVOIR
53
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
999
HOSE FROM RETURN LINE TO OIL TANK
999
NUT CHECK VALVE TO AIR RESERVOIR
