Поз.
Артикул
Описание
3
WASHER COVER PLATE TO FRAME
4
LOCK WASHER FITTING TO BRACKET
5
NUT STRAP TO SUPPORT
6
SCREW SUPPORT TO CROSS MEMBER M 10X28
6
SCREW HAND PUMP TO BRACKET
7
WASHER
8
LOCK WASHER FITTING TO BRACKET
11
NUT BRACKET TO SUPPORT AND TO END PIECE
13
BRACKET
15
WASHER
16
LOCK PLATE INTERMEDIATE BEARING
17
NUT
20
SCREW , Replaced By: N308676012012
20
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
23
WASHER
26
LOCK WASHER FITTING TO BRACKET
29
NUT STRAP TO SUPPORT,5 149419
999
ANGLE REAR LEFT, 002,003,010 UP TO IDENT NO. 752204, 101,102 UP TO IDENT NO. 734559
999
ANGLE FRONT LEFT, 002,003,010 UP TO IDENT NO. 752204, 101,102 UP TO IDENT NO. 734559
999
BRACKET , 002,003,010 UP TO IDENT NO. 752204, 101,102 UP TO IDENT NO. 734559
999
CLAMPING SCREW , 002,003,010 UP TO IDENT NO. 752204, 101,102 UP TO IDENT NO. 734559
999
ROLLER , 002,003,010 UP TO IDENT NO. 752204, 101,102 UP TO IDENT NO. 734559
