Поз.
Артикул
Описание
7
CROSS MEMBER , Replaced By: A6743101337, +001A6743102609
7
CROSS MEMBER TRANSMISSION
7
CROSS MEMBER TRANSMISSION
11
REINFORCEMENT LEFT
11
REINFORCEMENT RIGHT
13
REINFORCEMENT , Replaced By: A6763111460
13
REINFORCEMENT LEFT
13
REINFORCEMENT , Replaced By: A6763111560
13
REINFORCEMENT RIGHT
13
REINFORCEMENT RIGHT
15
ANGLE , Replaced By: A6733121252
15
ANGLE LEFT
15
ANGLE , Replaced By: A6733121152
15
ANGLE LEFT,5 519078
15
ANGLE LEFT,5 519078
15
ANGLE LEFT
15
ANGLE LEFT,5 519078
15
ANGLE LEFT
15
ANGLE LEFT,5 519078
17
ANGLE , Replaced By: A6763121052
17
ANGLE LEFT
17
ANGLE , Replaced By: A6763121152
17
ANGLE RIGHT
19
REINFORCEMENT LEFT
19
REINFORCEMENT RIGHT,5 519079
19
REINFORCEMENT LEFT
19
REINFORCEMENT RIGHT,5 519079
19
REINFORCEMENT LEFT
19
REINFORCEMENT RIGHT,5 519079
21
REINFORCEMENT LEFT
21
REINFORCEMENT RIGHT
21
REINFORCEMENT LEFT
21
REINFORCEMENT RIGHT
21
REINFORCEMENT LEFT
21
REINFORCEMENT , Replaced By: A6753112460
21
REINFORCEMENT LEFT
21
REINFORCEMENT RIGHT
21
REINFORCEMENT , Replaced By: A6753112560
21
REINFORCEMENT RIGHT
21
REINFORCEMENT LEFT
21
REINFORCEMENT RIGHT
21
REINFORCEMENT LEFT
21
REINFORCEMENT RIGHT
21
REINFORCEMENT LEFT
21
REINFORCEMENT RIGHT,5 519079
23
REINFORCEMENT , Replaced By: A6763111360
23
REINFORCEMENT LEFT AND RIGHT
23
REINFORCEMENT LEFT AND RIGHT
23
REINFORCEMENT LEFT AND RIGHT
25
SCREW END PIECE TO EXHAUST PIPE M 10X25
25
SCREW , Replaced By: N308676012012
25
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
25
SCREW CONSOLE TO SIDE MEMBER
25
SCREW END PIECE TO EXHAUST PIPE M 10X25
25
SCREW END PIECE TO EXHAUST PIPE M 10X25
25
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
25
SCREW BRACKET TO PROPELLER SHAFT BEARING HOUSING M 12X30
25
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
25
SCREW BRACKET TO PROPELLER SHAFT BEARING HOUSING M 12X30
25
SCREW EXHAUST PIPE TO BRACKET
25
SCREW CONSOLE TO SIDE MEMBER
25
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
25
SCREW CONSOLE TO SIDE MEMBER
27
SCREW REAR EXHAUST PIPE TO MUFFLER
27
SCREW REAR EXHAUST PIPE TO MUFFLER
27
SCREW , Replaced By: N308676012026
27
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
27
SCREW REAR EXHAUST PIPE TO MUFFLER
27
SCREW CONSOLE TO SIDE MEMBER
27
SCREW BRACKET TO FRAME M 12X35
27
SCREW BRACKET TO CROSS MEMBER M 12X1.5X40
27
SCREW BRACKET TO CROSS MEMBER M 12X1.5X40
27
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
29
NUT , Replaced By: N910113010000
29
NUT STRAP TO BRACKET
29
NUT SUPPORT TO SIDE MEMBER
29
NUT STRAP TO BRACKET
29
NUT STRAP TO SUPPORT
29
NUT SUPPORT TO SIDE MEMBER
29
NUT SUPPORT TO SIDE MEMBER
31
BRACKET , Replaced By: A6743102609, +001A6743101337
31
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 519078, Replaced By: A6743103909
31
BRACKET P.T.O.
31
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 519078, Replaced By: A6743103909
31
BRACKET P.T.O.
34
SCREW , Replaced By: N308676012012
34
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
34
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
37
WASHER
45
NUT SUPPORT TO SIDE MEMBER
45
NUT SUPPORT TO SIDE MEMBER
51
SCREW , Replaced By: N308676012026
51
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
51
SCREW BRACKET TO FRAME M 12X35
51
SCREW BRACKET TO FRAME M 12X35
51
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
51
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
54
WASHER BRACKET TO FRAME
54
WASHER BRACKET TO FRAME
57
NUT SUPPORT TO SIDE MEMBER
57
NUT , Replaced By: N910113012003
57
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
57
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
58
RIVET REAR CROSS MEMBER 12X42 MM
59
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
62
GROMMET I.D., / O.D., 72/88 MM
62
GROMMET I.D., / O.D., 72/88 MM
62
GROMMET I.D., / O.D., 72/88 MM
65
CONSOLE BODY MOUNTING
65
CONSOLE BODY MOUNTING
68
RIVET REINFORCEMENT TO SIDE MEMBER
68
RIVET GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS 10X26 MM
68
RIVET12X58 MM, TO BE ADAPTED DURING ASSEMBLY
999
ANGLE LEFT
999
CONSOLE , Replaced By: A6733171101
999
ANGLE , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733121052
