Поз.
Артикул
Описание
190
PITMAN ARM
190
PITMAN ARM ,K 055089
190
PITMAN ARM ,5 424630
190
PITMAN ARM ,K 055089
190
PITMAN ARM ,K 055089
190
PITMAN ARM , Replaced By: A6754631701
190
PITMAN ARM ,K 055088
190
PITMAN ARM ,5 424631K 055088
195
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
200
STEERING SUPPORT ,K 055088
200
STEERING BRACKET ,K 055089
200
STEERING BRACKET
200
STEERING BRACKET
200
STEERING SUPPORT (STEERING BRACKET)
200
STEERING SUPPORT ,K 055088
200
STEERING BRACKET ,K 055088
200
STEERING BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6764600129
200
STEERING SUPPORT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6764610440
205
STEERING SUPPORT ,K 055089
210
BRACKET AIR INTAKE PIPE
215
BRACKET STEERING MOUNTING,K 055089
220
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
220
SCREW , Replaced By: N304017008016
225
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
230
SCREW CLAMP TO BRACKET AND TO PIPE
235
WASHER EXHAUST MUFFLER TO STRAP
235
WASHER , Replaced By: N000125008443
240
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
240
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
245
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
245
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
245
SCREW , Replaced By: N308676016006
245
SCREW , Replaced By: N308676016007
250
SCREW , Replaced By: N308676020015
250
FITTED SCREW STEERING TO STEERING BRACKET M 20X40,K 055089
250
SCREW ENGINE REAR SUPPORT M 20X1.5X50
250
SCREW BRACKET TO REAR AXLE M 20X1.5X40
255
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X80
255
HEXAGON HEAD BOLT. SCREW TRAILER COUPLING TO REAR CROSS MEMBER,5 734466
255
SCREW , Replaced By: N308765016002
260
NUT , Replaced By: N910113016001
260
NUT CONSOLE TO SUPPORT
265
DRAG LINKLEMFOERDER,K 055088
265
DRAG LINKEHRENREICH
265
DRAG LINKLEMFOERDER,K 055089
265
DRAG LINKLEMFOERDER,5 424631K 054643
265
DRAG LINKEHRENREICH,5 424630
265
DRAG LINKEHRENREICH,5 424631K 054643
265
DRAG LINKLEMFOERDER
265
DRAG LINKEHRENREICH,K 055088
265
DRAG LINKEHRENREICH
265
DRAG LINKLEMFOERDER
265
DRAG LINKLEMFOERDER,K 054644
265
DRAG LINKLEMFOERDER,K 054644
265
DRAG LINKEHRENREICH,5 424630
265
DRAG LINKLEMFOERDER,K 055088
265
DRAG LINKLEMFOERDER,5 424630
265
DRAG LINK , Replaced By: A6754602405
265
DRAG LINK , Replaced By: A6754602505
265
DRAG LINK , Replaced By: A6754603005
265
DRAG LINK , Replaced By: A6754603105
265
DRAG LINKEHRENREICH,K 055088
265
DRAG LINKLEMFOERDER,5 424631K 054643
265
DRAG LINKLEMFOERDER,5 424630
265
DRAG LINKEHRENREICH,5 424631K 054643
270
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
270
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
270
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
270
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
275
SCREW TORSION BAR TO SHACKLE,5 903514
275
SCREW BRACKET TO CONSOLE M 12X1.5X65
275
SCREW ,5 903514, Replaced By: N000960012353
280
NUT , Replaced By: N910113012003
280
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
285
DRAG LINK END TO BE SCREWED INTO DRAG LINK EHRENREICH
285
DRAG LINK END , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004602648
285
DRAG LINK END , Replaced By: A0004602748
285
JOINT R.H. THREAD LEMFOERDER,5 180856
285
DRAG LINK END ,K 055088
295
NUT , Replaced By: N000979020000
295
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
295
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
300
COTTER PINROCKINGER TYP 260 G140
999
BOOT FIXED PART OF JOINT
999
BOOT FIXED PART OF JOINT
999
BOOT SCREWED PART OF JOINT
999
HOSE
999
CLAMP LINE MOUNTING
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
STEERING BRACKET
999
LINE , Replaced By: A0004291001
999
STEERING SUPPORT (STEERING BRACKET),K 244309
999
BRACKET AIR INTAKE PIPE
999
SCREW STEERING TO STEERING BRACKET,K 244309
999
LINE , Replaced By: A0004292301
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,5 163366
999
DRAG LINKLEHMFOERDER,5 426402
999
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 163366
999
PITMAN ARM , Replaced By: A6754632201, +001A6754603605, +001A6764600129, +001A6754600835
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 163366
999
BRACKET OIL TANK
999
STEERING SHAFT ,5 426402
999
STEERING SHAFT
999
STEERING SUPPORT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6754612340
999
LINE HIGH PRESSURE, FROM HOSE TO STEERING,K 055018
999
LINE , Replaced By: A0004291601
999
STEERING BRACKET
999
BRACKET OIL TANK,5 424631
999
STEERING SUPPORT (STEERING BRACKET),5 426402
