Поз.
Артикул
Описание
14
FUEL TANK ,K 169122, Replaced By: A6744700701, +001A0005409917, +001A0115426417
14
FUEL TANK LESS SENDER UNIT 70 L,K 169123
20
COVER BLIND COVER TO TANK,K 169123
20
COVER BLIND COVER TO TANK,K 169123
23
GASKET BLIND COVER TO TANK,K 169123
23
GASKET BLIND COVER TO TANK,K 169123
23
GASKET BLIND COVER TO TANK,K 169123
23
GASKET BLIND COVER TO TANK,K 169123
26
SCREW OIL LINE TO CRANKCASE
26
SCREW OIL LINE TO CRANKCASE
26
SCREW OIL LINE TO CRANKCASE
26
SCREW OIL LINE TO CRANKCASE
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
29
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
32
NUT , Replaced By: N913004006001
32
NUT PUMP TO BRACKET
32
NUT PUMP TO BRACKET
32
NUT PUMP TO BRACKET
32
NUT PUMP TO BRACKET
35
FILLER NECK FUEL TANK
35
FILLER NECK FUEL TANK
66
FUEL STRAINER FUEL TANK,K 169123
68
SENDER UNIT , Replaced By: A0085427817
68
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426417, +001A0005409917
68
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426417, +001A0005409917
68
SENDER UNIT FUEL GAUGE,K 169123
70
PLUG TO SEAL AUXILIARY HEATER CONNECTION 8 MM,K 169123
82
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
82
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
82
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
86
CONNECTOR FEED LINE AND RETURN LINE 12,5X1,25 MM
86
CONNECTOR FEED LINE AND RETURN LINE 11X1,5 MM
86
CONNECTOR FEED LINE AND RETURN LINE 8X1 MM
88
GASKET KIT CONNECTION ON FUEL GAUGE SENSOR
90
LOCK FUEL GAUGE SENDER UNIT CONNECTION
96
SCREW PLUG FUEL TANK
96
SCREW PLUG FUEL TANK
96
SCREW PLUG FUEL TANK
96
SCREW PLUG , Replaced By: A2109970132
96
SCREW PLUG
96
SCREW PLUG , Replaced By: A1159970032
96
SCREW PLUG , Replaced By: A2109970132
98
SEAL RING AT TANK, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
98
SEAL RING AT TANK, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
98
SEAL RING FUEL LINE TO FEED PUMP
98
SEAL RING FUEL LINE TO FEED PUMP
98
SEAL RING FUEL LINE TO FEED PUMP
106
SUPPORT FUEL TANK,FRONT AND REAR
106
SUPPORT FUEL TANK,FRONT AND REAR
122
SCREW CONSOLE TO SIDE MEMBER
122
SCREW , Replaced By: N308676012026
122
SCREW , Replaced By: N308676012026
122
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
122
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
122
SCREW , Replaced By: N000961012025
122
SCREW SUPPORT TO SIDE MEMBER
122
SCREW SUPPORT TO SIDE MEMBER
122
SCREW BRACKET TO SIDE MEMBER
122
SCREW BRACKET TO SIDE MEMBER
128
WASHER BRACKET TO FRAME
128
WASHER BRACKET TO FRAME
128
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
137
STRAP FUEL TANK TO SUPPORT
137
STRAP FUEL TANK TO SUPPORT
143
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
143
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
143
PAD FUEL TANK TO CONSOLE, ORDER BY THE METER
146
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
146
PAD EXPANSION TANK TO SUPPORT
152
NUT SUPPORT TO SIDE MEMBER
152
NUT SUPPORT TO SIDE MEMBER
158
PIN STRAP TO SUPPORT
158
PIN STRAP TO SUPPORT
161
COTTER PIN STRAP TO SUPPORT
161
COTTER PIN STRAP TO SUPPORT
161
COTTER PIN STRAP TO SUPPORT
164
WASHER STRAP TO SUPPORT
164
WASHER STRAP TO SUPPORT
