Поз.
Артикул
Описание
86
BRACKET COMPRESSED AIR LINE
89
SCREW END PIECE TO EXHAUST PIPE M 10X25
92
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
92
WASHER , Replaced By: N006902011102
92
WASHER , Replaced By: N006902011100
95
NUT STRAP TO BRACKET
95
NUT , Replaced By: N910113010000
98
CLAMP BRAKE HOSE BRACKET
101
SCREW CLAMP TO BRACKET
101
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
104
NUT PUMP TO BRACKET
104
NUT , Replaced By: N913004006001
119
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
119
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
122
UNION NUT LINE CONNECTION
122
UNION NUT LINE CONNECTION, Replaced By: N000000006239
125
SEAL CONE LINE CONNECTION
125
GLAND , Replaced By: A0019901967
128
FITTING DIAPHRAGM CYLINDER,CONNECTION:
131
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
131
CONNECTOR FROM REAR BRAKE HOSE TO TRISTOP CYLINDER TO M 22
134
CONNECTOR HOSE WIDTH, 9 MM, TO M 22
134
CONNECTOR HOSE WIDTH, 9 MM, TO M 22
137
CONNECTOR COMPRESSED AIR LINE THRU RIGHT SIDE MEMBER TO M 22
140
LOCK REAR AXLE BRAKE HOSE,K 181360
143
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
143
CLAMP HOSE TO FITTING AND TO OIL TANK
146
NUT BRACKET TO SIDE MEMBER
146
NUT BRACKET TO SIDE MEMBER
149
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
149
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
152
THRUST RING CHECK VALVE TO AIR RESERVOIR
152
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
155
O-RING CHECK VALVE TO AIR RESERVOIR
158
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
158
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
158
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
158
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
158
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
158
TEST CONNECTION
161
PLUG
164
TEST CONNECTION SHUTTLE VALVE,CONNECTION: "2"
164
TEST CONNECTION SHUTTLE VALVE,CONNECTION: "2"
167
SEAL RING LINE CONNECTION
999
CONNECTOR ,5 288358, Replaced By: A0019901378, +001A6734210073
999
CLAMP BRAKE HOSE
999
HOSE COMPRESSED AIR GUIDE, REAR AXLE. 220 MM
999
CLAMP BRAKE HOSE
