Поз.
Артикул
Описание
7
EXHAUST PIPE FRONT,FRONT PART
7
EXHAUST PIPE ,5 151698-5 258346,10/505 258346,20/60, Replaced By: A6734902919, +001A6734903019
7
EXHAUST PIPE ,5 151698-5 258346,10/505 258346,20/60, Replaced By: A6734902919, +001A6734903019
7
EXHAUST PIPE FRONT,FRONT PART,5 544987
7
EXHAUST PIPE FRONT,FRONT PART,5 544987
7
EXHAUST PIPE FRONT,FRONT PART,5 544988
22
EXHAUST PIPE FRONT,FRONT PART
22
EXHAUST PIPE ,5 195248, Replaced By: A6734902419, +001A6734902519, +001A6734902141
22
EXHAUST PIPE FRONT,FRONT PART,5 195249
30
EXHAUST PIPE FRONT CENTRAL,5 195249
41
EXHAUST PIPE FRONT,REAR PART,5 151697
47
EXHAUST PIPE , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 5 151698-5 229872, Replaced By: A6734902819
47
EXHAUST PIPE ,5 151698-5 258346,10/505 258346,20/60, Replaced By: A6734903019, +001A6734902919
47
EXHAUST PIPE FRONT,REAR PART,5 2583475 325174
47
EXHAUST PIPE FRONT,5 325175
56
EXHAUST PIPE EXHAUST PIPE TO EXHAUST MANIFOLD
56
EXHAUST PIPE FRONT,REAR PART
56
EXHAUST PIPE FRONT,REAR PART
56
EXHAUST PIPE FRONT,REAR PART
56
EXHAUST PIPE FRONT,REAR PART
56
EXHAUST PIPE FRONT,REAR PART
58
EXHAUST PIPE FRONT,REAR PART
84
HEXAGON HEAD BOLT. SCREW THROTTLE HOUSING TO FRONT EXHAUST PIPE M 12X70
86
NUT THROTTLE HOUSING AND BRACKET TO FRONT EXHAUST PIPE
97
THROTTLE HOUSING , Replaced By: A3661405353
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
97
THROTTLE HOUSING , Replaced By: A3661405353
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
97
THROTTLE HOUSING ,K 181319
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
97
THROTTLE HOUSING ,K 181319
97
THROTTLE HOUSING , Replaced By: A3661402453, +001A3661440040, +001A4221440174, +001A0004304226, +001A4039910222, +001N000439008209, +001N000934008010, +003N007349008003, +001N071805013403, +001N914126008037, +001N999900008004
97
THROTTLE HOUSING , Replaced By: A3661402253
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
97
THROTTLE HOUSING ,5 163561
97
THROTTLE HOUSING , Replaced By: A3661402353
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
97
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
100
VALVE PARTS KIT,K 181318N 817421 - N 825202
100
VALVE PARTS KIT,K 181318N 817421 - N 825202
100
VALVE , Replaced By: A3661401963
100
VALVE PARTS KIT,K 181319
100
VALVE PARTS KIT,K 181318N 817421 - N 825202
100
VALVE , Replaced By: A3661402063
100
VALVE PARTS KIT,K 181319
100
VALVE , Replaced By: A3661401063
100
VALVE PARTS KIT,5 163561
100
VALVE , Replaced By: A3661401163
100
VALVE PARTS KIT,K 181318N 817421 - N 825202
100
VALVE PARTS KIT,K 181318N 817421 - N 825202
106
BUSHING
106
BUSHING THROTTLE VALVE SHAFT
112
LEVER EXHAUST-BRAKE THROTTLE VALVE
112
LEVER , Replaced By: A3661400232, +001N913017006000, +001N914126006025
115
BALL PIVOT BOTTOM B13X5 MM
120
SCREW , Replaced By: N910105006005
120
SCREW , Replaced By: N000000001479
120
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
120
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
123
NUT , Replaced By: N910112006001
123
NUT , Replaced By: N913023006001
123
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
123
NUT BALL PIVOT TO LEVER
127
CYLINDER , Replaced By: A0004305926
127
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
127
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
127
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
127
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
139
BUSHING"WABCO"
139
BUSHING"WABCO"
139
BUSHING , Replaced By: A0004340850
139
BUSHINGTO 000 430 30 26/32 26
139
BUSHING"WABCO"
145
REPAIR KITTO 000 430 48 26,KNORR
145
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
145
REPAIR KITTO 000 430 48 26,KNORR
148
CAP SHIFTING CYLINDER TO 000 430 48 26 , 49 26
148
CAP SHIFTING CYLINDER TO 000 430 48 26 , 49 26
157
NUT , Replaced By: N304035008001
157
NUT
163
BALL SOCKET
163
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
169
SECURING CLIP. CIRCLIP
181
PIN INTERMEDIATE SPEED STOP
181
PIN , Replaced By: A4421440574
181
PIN CYLINDER TO BRACKET
181
PIN INTERMEDIATE SPEED STOP
187
WASHER , Replaced By: N000125008443
187
WASHER EXHAUST MUFFLER TO STRAP
193
NUT
193
NUT , Replaced By: N913004008001
193
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
196
SCREW , Replaced By: A0099900101
196
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
199
WASHER INTERMEDIATE SPEED STOP
199
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
199
WASHER INTERMEDIATE SPEED STOP
205
NUT
205
NUT
205
NUT , Replaced By: A0009903250
205
NUT POWER CYLINDER TO BRACKET
207
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 077169/N 817421 - 825202, Replaced By: A3661440440
207
BRACKET POWER CYLINDER, TO BE ADAPTED DURING ASSEMBLY
209
SCREW BRACKET TO THROTTLE HOUSING M 8X16
209
SCREW BRACKET TO THROTTLE HOUSING M 8X20
213
SCREW , Replaced By: A0099900101
213
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
215
NUT POWER CYLINDER TO BRACKET
999
SCREW SHAFT TO THROTTLE VALVE
999
NUT
999
EXHAUST PIPE RESONATOR
999
BRACKET
999
EXHAUST PIPE RESONATOR,K 049384
999
EXHAUST PIPE. EXHAUST GAS LINE FRONT,K 049384
999
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD
999
EXHAUST PIPE RESONATOR,K 049384
999
EXHAUST PIPE FRONT, TO BE ADAPTED DURING ASSEMBLY
999
EXHAUST PIPE RESONATOR,K 049384
999
EXHAUST PIPE RESONATOR,K 049384
999
EXHAUST PIPE REAR EXHAUST PIPE TO DAMPING PAD
999
EXHAUST PIPE REAR,K 023163
999
EXHAUST PIPE REAR EXHAUST PIPE TO DAMPING PAD
999
EXHAUST PIPE FRONT
999
EXHAUST PIPE , Replaced By: A6754900721
999
EXHAUST PIPE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6754900221
999
EXHAUST PIPE
999
EXHAUST PIPE FRONT,FRONT PART,5 541031N 817222
999
EXHAUST PIPE FRONT
999
EXHAUST PIPE FRONT CENTRAL,5 536226
999
EXHAUST PIPE CONNECTING PIPE TO EXHAUST MANIFOLD,5 337343
999
PROTECTIVE PLATE FRONT
999
EXHAUST PIPE FRONT
999
EXHAUST PIPE FRONT
999
EXHAUST PIPE FRONT,5 529481
999
EXHAUST PIPE FRONT
999
EXHAUST PIPE FRONT,5 325175
