Поз.
Артикул
Описание
5
11
BRACKET , Replaced By: A9794300010
11
BRACKET AIR RESERVOIR
17
SCREW BRACKET TO FRAME SIDE MEMBER
20
NUT BRACKET TO SIDE MEMBER,XB209706
26
30
NUT BRACKET TO RETARDER
31
NUT CABLE TO STARTING MOTOR,TERMINAL 30
32
CONNECTOR AIR RESERVOIR,CONNECTION: "3"
35
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
38
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
41
SEAL RING LINE CONNECTION
44
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
47
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
