Поз.
Артикул
Описание
56
HOUSING OIL COOLER
56
HOUSING , Replaced By: A0002710301
68
WASHER EXHAUST MUFFLER TO STRAP
71
SCREW , Replaced By: N000000001448
71
HEXALOBULAR BOLT. SCREWM 8X45
74
SEAL RING PNEUMATIC VALVE
77
SCREW PLUG, FILLING HOUSING,BOTTOM
77
SCREW PLUG , Replaced By: N000000000648
80
SEALING RING. SEAL RING ENGINE BREATHING
83
SCREW PLUGTO 000 553 03 05,000 553 18 05,
86
RESERVOIR RETARDER ACCUMULATOR
86
RESERVOIR , Replaced By: A0002700446
86
RESERVOIR , Replaced By: A0002700546
89
COVER
92
COVER
95
PIPE
95
PIPE , Replaced By: A0002712696
98
PISTON
101
SEAL RING
104
SEAL RING
104
SEAL RING , Replaced By: A0199975947
107
PISTON GUIDE
110
STUD
113
WASHER EXHAUST MUFFLER TO STRAP
116
NUT , Replaced By: N913004008001
116
NUT , Replaced By: N913004008004
119
SEAL RING RESERVOIR TO OIL COOLER HOUSING
122
WASHER EXHAUST MUFFLER TO STRAP
125
HEXALOBULAR BOLT. SCREWM 8X45
125
SCREW , Replaced By: N000000001448
128
VALVE (SOLENOID VALVE)
131
SEAL RING LINE CONNECTION
134
SCREW PLUG
134
SCREW PLUG , Replaced By: A0029973430
137
SEAL RING SOLENOID VALVE TO OIL COOLER HOUSING
140
WASHER EXHAUST MUFFLER TO STRAP
143
SCREW VALVE TO BRACKET M 8X55
143
SCREW , Replaced By: N304017008043
146
BRACKET , Replaced By: A0002710388
146
COVERING RETARDER ACCUMULATOR
149
SPACER WASHER RETARDER ACCUMULATOR 2.00 MM
149
SPACER WASHER RETARDER ACCUMULATOR, AS REQUIRED 0.80 MM
149
SPACER WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
149
SPACER WASHER , Replaced By: A0002710152, +001A0002710352
149
SPACER WASHER , Replaced By: A4602840552
149
SPACER WASHER , Replaced By: A4602840352
149
SPACER WASHER , Replaced By: A4602840352
149
SPACER WASHER , Replaced By: A4602840352
149
SPACER WASHER , Replaced By: A4602840352
152
WASHER , Replaced By: A4602840352
152
WASHER , Replaced By: A4602840352
152
WASHER BRACKET TO RETARDER ACCUMULATOR 1.20 MM
152
WASHER BRACKET TO RETARDER ACCUMULATOR 0.80 MM
152
SPACER WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
152
WASHER BRACKET TO RETARDER ACCUMULATOR 0.60 MM
152
WASHER RETARDER ACCUMULATOR, AS REQUIRED 1.00 MM
155
WASHER EXHAUST MUFFLER TO STRAP
158
SCREW BRACKET TO CROSS CONNECTION STRUT
161
NUT
164
SEAL RING OIL LINE
164
SEAL RING , Replaced By: A0209970948
167
PIPE OIL COOLER,TOP AND BOTTOM
999
SEALING STRIP , LENGTH AVAILABLE 12000 MM
