Поз.
Артикул
Описание
5
PLASTIC PIPE AERATION, ORDER BY THE METER
15
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
15
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
15
ELBOW FITTING , Replaced By: A0049905371
20
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
25
LOCK RING LINE CONNECTION
25
SEAL RING , Replaced By: A0009940747
30
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
35
LOCK LINE CONNECTION
35
LOCK , Replaced By: A0009945448
40
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
45
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
45
REPAIR KIT , Replaced By: A0309971748
50
VALVE FRONT AXLE LEVEL ADJUSTMENT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
50
VALVE FRONT AXLE LEVEL ADJUSTMENT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
55
VALVE TRAILING AXLE SELF-LEVELLING DEVICE
55
VALVE PNEUMATIC SUSPENSION BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
60
VALVE INTAKE
65
VALVE EXHAUST
70
SHAFT87 MM
75
LEVER (PARTS KIT)
80
REPAIR KIT
85
BRACKET 3/2-WAY VALVE
90
BRACKET 3/2-WAY VALVE
95
SCREW PIPE CLAMP
100
HEXAGON HEAD BOLT. SCREW LEVEL ADJUSTMENT VALVE TO SUBSTRUCTURE
100
HEXAGON HEAD BOLT. SCREW LEVEL ADJUSTMENT VALVE TO SUBSTRUCTURE
105
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
110
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
110
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
115
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
120
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
125
NUT , Replaced By: N304032008006
130
VALVE LEVEL ADJUSTMENT VALVE,CONNECTION: "10"
135
FITTING LINE CONNECTION
135
FITTING LINE CONNECTION, Replaced By: N000000006446
140
SEAL RING 3/2-WAY VALVE
140
SEAL RING SRREW PLUG
150
SEAL RING 3/2-WAY VALVE
150
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
150
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
155
BREATHER FILTER. FILTER TRAILER CONTROL VALVE,CONNECTION: "4"
160
SCREW PLUGROCKINGER,TYP 59 U150
160
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
165
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
170
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
170
T-FITTING 3/2-WAY VALVE
170
T-FITTING
170
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
180
MUFFLER TRAILER CONTROL VALVE
185
FITTING LINE CONNECTION
190
FITTING AT AIR RESERVOIR
200
SEAL RING 3/2-WAY VALVE
200
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
200
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
205
SCREW. UNION SCREW LINE CONNECTION
205
SCREW. UNION SCREW , Replaced By: A0009973734
210
NUT CHECK VALVE TO AIR RESERVOIR
