Поз.
Артикул
Описание
5
DIFFERENTIAL GEAR LESS FLANGE
5
DIFFERENTIAL GEAR LESS FLANGE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
AXLE HOUSING , Replaced By: A3953504620
8
AXLE HOUSING WITH BEARING CAP
8
BRAKE SHOE WITH BEARING CAP
11
CYLINDRICAL PIN
11
CYLINDRICAL PIN , Replaced By: N000007008101
14
SCREW BEARING COVER TO AXLE HOUSING
17
PIN AXLE HOUSING
20
SNAP RING
23
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.10 MM
23
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.15 MM
23
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.50 MM
23
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.00 MM
26
HOUSING , Replaced By: A3463530807, +001N000906020003
26
HOUSING PINION HOUSING
29
SCREW APPARATUS SUPPORT TO FRAME
29
SCREW , Replaced By: A9429901304
32
SEAL RING PINION HOUSING TO AXLE HOUSING
128
SCREW , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3559901704
128
SCREW REAR AXLE HOUSING TO AXLE CASING M 12X35
128
SCREW REAR AXLE HOUSING TO AXLE CASING M12 X 35
128
SCREW BRACKET TO BRACKET
134
SCREW PINION HOUSING TO AXLE HOUSING M12X1,5X85
134
HEXAGON HEAD BOLT COVER TO DIFFERENTIAL CASE M12X1.5X85
137
COVER
140
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
143
SCREW PIPE CLAMP
