Mercedes
AXLE
NL 4/50 DCL - 7,5
749.109
39 TRAILING AXLE
001 DETACHABLE BODY COMPONENTS AND INSTALLATION PARTS, TRAILING AXLE ABLE TO BE RAIS IL.6

Mercedes N000000001571 - БОЛТ М10

NL 4/50 DCL - 7,5 749.109

39 TRAILING AXLE - 001 DETACHABLE BODY COMPONENTS AND INSTALLATION PARTS, TRAILING AXLE ABLE TO BE RAIS IL.6

Поз.
Артикул
Описание
320
QP15463010B
PITMAN ARM , TO BE ORDERED ONLY FROM MESSRS FA.PAUL-NUTZFAHRZEUGE GMBH&CO.KGD-94036 PASSAU DANZIGERSTRASSE 49
320
QP15463012B
PITMAN ARM , TO BE ORDERED ONLY FROM MESSRS FA.PAUL-NUTZFAHRZEUGE GMBH&CO.KGD-94036 PASSAU DANZIGERSTRASSE 49
320
A6624630201
PITMAN ARM
320
A0003380114
INTERMEDIATE ARM , Replaced By: A6624630201
330
A0019908151
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
420
A6294660092
CYLINDER (POWER CYLINDER),POWER STEERING
425
A0014607048
DRAG LINK END SHORT 80 MM
430
N000935024000
NUT CYLINDER TO BEARING BRACKET AND PITMAN ARM M24X1.5
435
N000094005045
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
440
A0004660677
CLAMP DRAG LINK END
445
N000000001571
HEXALOBULAR BOLT CLAMP MOUNTING M10X55
450
N304032010003
NUT BATTERY CABLE
999
A0004600535
BRACKET POWER STEERING CYLINDER
