Поз.
Артикул
Описание
11
PART NAME MISSING. HEAT EXCHANGER
11
HEAT EXCHANGER ,P 753730
14
CONTROL UNIT , PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
14
CONTROL UNIT ,P 753730
14
CONTROL UNITOM 601/OM 602,P 753730
14
CONTROL UNIT , P 753731 R 000001
20
BLOWER ,P 753730
20
BLOWER ,P 753730
20
BLOWER , P 753731 R 000001
23
RESISTOR , 000925
26
STUD BLOWER, PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
29
TEMPERATURE SENSOR HEAT EXCHANGER TEMPERATURE SENSOR, PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
32
SWITCH OVERHEATING,P 753730
32
SWITCH OVERHEATING, PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
32
SWITCH , Replaced By: A0058202310
35
ELECTRIC CABLE SWITCH,P 753730
38
PRINTED CIRCUIT PLATE ,P 753730
41
SPRING HEAT EXCHANGER TEMPERATURE SENSOR,P 753730
41
SPRING HEAT EXCHANGER TEMPERATURE SENSOR
44
HEATER PLUG
47
SEAL , PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
50
FILTER ,P 753730
50
FILTER , PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
53
SEAL HEAT EXCHANGER, PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
53
SEAL HEAT EXCHANGER,P 753730
56
SEAL COVER,P 753730
56
SEAL COVER
59
SEAL ,P 753730
59
SEAL
68
SEAL FLANGE, PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
68
SEAL FLANGE,P 753730
71
COVERING TOP,P 753730
71
COVERING TOP, P 753731 R 000001
71
COVERING TOP
74
COVERING BOTTOM
74
COVERING BOTTOM, PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
77
RIVET
80
CAP ,P 753730
80
CAP , Replaced By: A0008310729
80
CAP , Replaced By: A0008310629
83
SPRING , Replaced By: N912010003000
83
SPRING , Replaced By: N912003005000
83
DUO CLIP , Replaced By: N912010005001
83
LOCK PLATE CONSOLE TO REAR PANELLING,TOP
83
LOCK PLATE , A 372464 ALSO INSTALLED ON A 372469,A 372476,A 372477,A 372483,A 372490,A 372493,A 372505,A 372517,A 372519,A 372525,A 372539,A 372548,A 372572,A 372614, A 373051.EXCEPT FOR A 371956 F 348473
86
SCOOP FUSE, P 753731 R 000001
86
SCOOP MAIL VEHICLES
107
HOSE , Replaced By: A0008325823
107
HOSE , PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
107
PIPE LINE , P 753731 R 000001
110
INSULATION DISTRIBUTOR TO HEATING DUCT, P 753731 R 000001
110
INSULATION ,P 753730
113
PIPE SOCKET ,P 753730
113
PIPE SOCKET ,P 753730
113
CAP , Replaced By: A0008360025
119
GRILLE ,P 753730
122
RING , P 753731 R 000001
128
CLAMP DRAG LINK END TO DRAG LINK
128
CLAMP PUMP TO BRACKET
128
CLAMP , Replaced By: A0003380563, +001N000960010023, +001N913004010010
128
CLAMPTO 638 835 12 01,13 01
128
LOOM TIE , Replaced By: A0008300068
131
PUMP
131
PUMP METERING PUMP, P 753731 R 000001
131
PUMP METERING PUMP,P 753730
134
PIPE LINE , P 753731 R 000001
137
BUFFER WIPER MOTOR TO REAR PANEL DOOR, ONLY FOR AUSTRALIA CODE 625
137
BUFFER , Replaced By: A1249880611
140
HOSE , Replaced By: A0009871727
140
PLASTIC PIPE FUEL SYSTEM 6X2 MM, ORDER BY THE METER
143
CLAMP , Replaced By: N916016034202
143
CLAMP PUMP TO BRACKET
146
CABLE STRAP REAR SWIVEL DOOR
146
HOSE CLAMP. CLAMP CONNECTION OF FUEL LINES 9MM
146
HOSE CLAMP. CLAMP , P 753731 R 000001
147
PLASTIC PIPE FUEL SYSTEM 6X2 MM, ORDER BY THE METER
148
HOSE
149
STRAINER
152
FITTING
155
CLAMP FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BRACKET
158
SCREW CLAMP MOUNTING M 6X16
161
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
161
NUT , Replaced By: N913023006001
164
BRACKET ADDITIONAL HEATER
173
WASHER COMPRESSED AIR LINE TO BRACKET
173
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
176
NUT
182
BRACKET METERING PUMP
185
NUT , Replaced By: N913023006001
185
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
188
PLUG INJECTION VALVE
191
CONTACT SPRING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0MM2,126372
194
CAP. BOOT ,126372
197
CLAMP
200
BRACKET OIL LINES
200
CLAMP ELECTRIC CABLE TO BRAKE HOSE
200
CLAMP. EXTENDABLE SPACER BREATHER LINE
206
LOOM TIE , Replaced By: A0029970190
206
LOOM TIE , Replaced By: A0049975190
206
LOOM TIE LINE MOUNTING
206
LOOM TIE ,P 753730
260
HOSE FROM AUXILIARY HEATER TO ENGINE
263
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
266
AIR INTAKE PIPE , PART IS ONLY VALID FOR D3LC COMPACT AIR HEATER (MAKE EBERSPAECHER) CAUTION: OBSERVE PART OF TEXT IN FDOC
269
DISTRIBUTOR
272
SEAL
275
SCREW-AND-WASHER ASSEMBLY HEAT EXCHANGER TO BODY
999
HOSE AIR INTAKE,P 753730
