Поз.
Артикул
Описание
5
FUEL TANK GASOLINE VEHICLES
5
FUEL TANK GASOLINE VEHICLES
5
FUEL TANK , Replaced By: A9014711898
5
FUEL TANK , Replaced By: A9014712298
5
FUEL TANK GASOLINE VEHICLES CODE-B:KBO (100LTR.)
8
STRAP , EXHAUST STOCK OF OLD PART NUMBERS FIRST, Replaced By: A9014700140
8
STRAP , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A9014700340
8
STRAP FUEL TANK MOUNTING
8
STRAP FUEL TANK MOUNTING
9
SHIM FUEL TANK FRONT SIDE,LEFT AND RIGHT
9
SHIM , Replaced By: A1294710195
11
SENDER UNIT GASOLINE VEHICLES,ONLY WITH AUXILIARY HEATER
11
SENDER UNIT GASOLINE VEHICLES,USED WITHOUT AUXILIARY HEATER
14
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
14
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
17
NUT FUEL GAUGE SENDER UNIT TO FUEL TANK
17
NUT FUEL GAUGE SENDER UNIT TO FUEL TANK
20
PIN BUSHING HOUSING FUEL GAUGE SENDER UNIT
23
WIRE SEAL
26
CONTACT SPRINGTO 657 540 50 10
29
FILLER NECK DIESEL VEHICLES, FILLER NECK MUST BE CONNECTED TO THE BODY SHELL WITH A GROUND LINE
29
FILLER NECK ,P 830165, Replaced By: A9014700720
29
FILLER NECK ,P 830165, Replaced By: A9014700820
29
FILLER NECK , Replaced By: A9014701020
29
FILLER NECK , Replaced By: A9014701120
29
FILLER NECK GASOLINE VEHICLES, FILLER NECK MUST BE CONNECTED TO THE BODY SHELL WITH A GROUND LINE
30
FLANGE , P 830166 R 000001
32
TAPPING SCREW FILLER PIPE MOUNTING 6.3X38
35
FILLER CAP
35
FILLER CAP , Replaced By: A9014700405
35
FILLER CAP
38
SEAL RINGTO 000 471 63 30, 000 471 74 30
38
SEAL RING
40
RIVET
41
HOSE FILLER NECK TO FUEL TANK
44
CLAMP HOSE FASTENING 50-70X13 MM
44
CLAMP , Replaced By: N000000000672
47
BREATHER PIPE , Replaced By: A4049970982
47
HOSE (PROTECTIVE HOSE) RETURN LINE TO COOLING PIPE 100 MM, ORDER BY THE METER
50
LOOM TIE HOSE ATTACHMENT, ONLY FOR R.S.A.
