Mercedes A0025450628 - КЛЕММА

324, 309CDI, 311CDI, 315CDI, 318CDI 906.631

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 095 RELAY,FUSEBOX AND CONTROL MODULES IN SEAT FRAME

Поз.
Артикул
Описание
10
A0008383006
VENTILATOR
20
A0008380018
GRILLE
30
A0009940143
FUSE
40
A0015458728
PIN BUSHING HOUSING BIPOLAR
50
A0015457928
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
70
A9018320003
COVER
80
N304017006020
SCREW LICENSE PLATE TO BRACKET
90
N000125006449
WASHER COMPRESSED AIR LINE TO BRACKET
100
N304032006004
NUT SPRING-LOADED PUSH ROD
200
A0008383306
VENTILATOR
210
N000000003291
HEXALOBULAR BOLT CHARGE SOCKET AT BRACKET M6X20
220
A3098300089
ESCUTCHEON ROOF MOUNTED VENTILATOR
240
A0009870772
EDGE GUARD SECTION , ORDER BY THE METER
250
A3098380220
ESCUTCHEON ROOF MOUNTED VENTILATOR
260
A3026180076
COVER
270
N000000000743
TAPPING SCREW LOWER GARNISH MOULDING
900
A0015457928
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
905
A0355458128
FLAT PLUG WITH DETENT 0.5-1.0 MM2
910
A0015457928
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
915
A0355458128
FLAT PLUG WITH DETENT 0.5-1.0 MM2
915
A0285455328
FLAT PLUG WITH DETENT 4-6 MM2
915
A0025450628
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
