Поз.
Артикул
Описание
5
5
5
8
8
GASKET MOUNTING FRAME,028481
11
SCREW DOOR CHECK TO BODY M8 X 20
11
12
ADHESIVE TAPE , Replaced By: A0039898585
12
ADHESIVE TAPE PIPING
15
PLATE SERVICE BRAKE VALVE TO PEDAL BEARING BRACKET, Replaced By: A9412920245
16
PLATE SERVICE BRAKE VALVE TO PEDAL BEARING BRACKET
17
17
PEDAL CLUTCH
17
20
PEDAL BRAKE
20
22
PAD CLUTCH PEDAL
23
PAD BRAKE PEDAL
24
STOP CLUTCH PEDAL AND BRAKE PEDAL
44
SPACER TUBE BRAKE PEDAL TO BEARING BRACKET
47
SPRING BRAKE PEDAL RESET
47
50
BUSHING BRAKE PEDAL
53
ROD PISTON ROD AND PUSH ROD
53
55
56
YOKE OPERATING ROD
56
YOKE SHIFTING ROD TO INTERMEDIATE LEVER
56
YOKE OPERATING ROD,K 202311
59
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
59
NUT
62
PIN ROD TO BRAKE PEDAL
62
PIN ROD TO BRAKE PEDAL,L 01.03.07B 01.03.07
65
WASHER BRACKET TO CROSS MEMBER
65
WASHER PULL ROD TO SHIFT LEVER
71
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
71
LOCK ROD TO BRAKE PEDAL,L 01.03.07B 01.03.07
74
PIN CLUTCH AND BRAKE PEDALS TO BEARING BRACKET
77
LOCK STOP TO BEARING BRACKET
77
LOCK RING , Replaced By: A0079942041
