Поз.
Артикул
Описание
830
VALVE PNEUMATIC SUSPENSION BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
832
VALVE INTAKE
834
VALVE EXHAUST
834
VALVE , Replaced By: A0003282125
836
SHAFT87 MM
838
SCREW PLUGROCKINGER,TYP 59 U150
838
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
840
SEAL RING SRREW PLUG
842
REPAIR KIT , Replaced By: A0003200258
842
REPAIR KIT
844
LEVER (PARTS KIT)
844
LEVER , Replaced By: A0003200127, +001A0003280014
846
SWITCH , Replaced By: A3575407645
846
SWITCH (LEVEL SWITCH)
848
WASHER COVERING TO BEARING BRACKET
850
BRACKET LEVEL ADJUSTMENT SWITCH
852
PLATE ON LEVEL ADJUSTMENT VALVE LEVER
854
SPACER ON LEVEL ADJUSTMENT VALVE LEVER
856
SCREW GRIP RAIL MOUNTING M 6 X 20
858
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
860
NUT PUMP TO BRACKET
860
NUT , Replaced By: N913004006001
862
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
FITTING LINE CONNECTION, Replaced By: N000000006446
