Поз.
Артикул
Описание
5
COVER SHIFT CASE
5
COVER , Replaced By: A0002686105, +002A0009977535
8
GASKET , Replaced By: A0002685780
8
GASKET , Replaced By: A0002680280
8
GASKET SHIFT CASE
11
HEXAGON HEAD BOLT CLAMP TO EXHAUST PIPE
11
SCREW , Replaced By: N304014010004
11
SCREW SHIFT CASE TO TRANSMISSION M 10X105
11
SCREW CLUTCH TO FLYWHEEL
11
SCREW BRACKET TO BELL HOUSING
14
SPRING WASHER STEERING COLUMN BRACKET TO CAB
17
SHAFT (SHIFTING SHAFT)
17
SHAFT (SHIFTING SHAFT)
20
CYLINDRICAL ROLLER SHIFTING SHAFT
23
FOLLOWER SHIFTING SHAFT
26
ROLLER SHIFTING SHAFT
29
FOLLOWER REVERSE SPEED
32
PIN SHIFTING SHAFT
35
FOLLOWER REVERSE SPEED
38
FOLLOWER 1ST AND 2ND SPEED
41
FOLLOWER 3RD AND 4TH SPEED
44
FOLLOWER SHIFTING SHAFT
47
SCREW FOLLOWER TO SHIFTING SHAFT
50
FOLLOWER SHIFTING SHAFT
53
SHIFTING SEGMENT SHIFTING SHAFT
53
SHIFTING SEGMENT , Replaced By: A0002680446
56
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
59
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
62
BUSHING SHIFTING SHAFT,BOTTOM
62
BUSHING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002684050
62
BUSHING SHIFTING SHAFT,BOTTOM
65
SPACER WASHER SHIFTING SHAFT
68
SPRING SHIFTING SHAFT,BOTTOM
71
SPACER RING SHIFTING SHAFT,BOTTOM
74
CLAMPING SLEEVE SHIFTING SHAFT,BOTTOM
77
COVER SHIFT LEVER TO TRANSMISSION
80
SHIFT LEVER
80
SHIFT LEVER , Replaced By: A0002682730
80
SHIFT LEVER , Replaced By: A0002684130
83
SCREW SHIFTING ROD TO JOINT
86
SPRING WASHER STEERING COLUMN BRACKET TO CAB
89
NUT
89
NUT , Replaced By: N304032010002
92
JOINT SHIFTING SHAFT,TOP
95
NUT , Replaced By: N910113010002
95
HEXAGON NUT
98
CONNECTOR SHIFTING TUBE TO SHIFT LEVER
101
NUT , Replaced By: N308673014001
101
NUT BRACKET TO SIDE MEMBER,K 035196
104
BALL JOINT UPPER PULL ROD
104
JOINT , Replaced By: A0002686189
104
JOINT TOP
107
NUT BRACKET TO TELESCOPIC TUBE,K 142858
110
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLY
113
NUT PULL ROD
116
JOINT BOTTOM
116
JOINT , Replaced By: A0002686289
119
NUT STRAP TO SUPPORT,5 149419
122
BRACKET BRACING
122
BRACKET LOWER SHIFTING ROD,001876,5 K 90 GP003321,5 S 90 GP
125
NUT BRACKET TO TELESCOPIC TUBE,K 142858
128
SCREW CLUTCH TO FLYWHEEL
128
SCREW CLUTCH TO FLYWHEEL
131
SPRING WASHER STEERING COLUMN BRACKET TO CAB
137
HOUSING SHIFTING DOME
140
GASKET SHIFT CASE,TOP AND BOTTOM
140
GASKET , Replaced By: A0002685180
146
SCREWM 8X40
149
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
149
SPRING WASHER , Replaced By: N000137008212
155
SEAL RING SHIFTING DOME,TOP
158
BUSHING SHIFTING DOME,TOP
161
SEAL RING SHIFTING SHAFT
164
BOOT SHIFTING SHAFT
167
VALVE BREATHER, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
173
SCREW PLUG STABILIZER
176
BUSHING SHIFT CASE,TOP
179
PIN INTERLOCK PIN
182
COVER SHIFT CASE,BOTTOM
185
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
185
SCREW , Replaced By: N304017008027
188
SCREW , Replaced By: N000933008134
188
SCREW FRONT AXLE REGULATING SOLENOID VALVE
191
STUD COVER TO SHIFT CASE
194
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
194
SPRING WASHER , Replaced By: N000137008212
197
NUT , Replaced By: N304032008006
197
NUT
200
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002683974
200
PIN SHIFT CASE,BOTTOM
203
SPRING SHIFT CASE
206
NEEDLE BEARING REAR DRIVE SHAFT
206
NEEDLE BEARING , Replaced By: A0059813110
209
CABLE PULLEY SHIFT CASE,BOTTOM
212
PIN SHIFT CASE,BOTTOM
215
SPRING SHIFT CASE,FRONT
218
SCREW PLUG SHIFT CASE,BOTTOM
221
SEAL RING LINE CONNECTION
224
PIN
227
SLOTTED GATE
230
GASKET VALVE TO TRANSMISSION
230
GASKET , Replaced By: A0002685080
233
SCREW CLAMP TO BRACKET AND TO PIPE
236
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
236
SPRING WASHER , Replaced By: N000137008212
239
SCREW PLUG TOP AND BOTTOM
242
SCREW PLUG BELL HOUSING
242
PLUG , Replaced By: A3529970032
245
EXPANSION PLUG ROD END
248
SCREW PLUG
251
EXPANSION PLUG HOUSING,BOTTOM
251
COVER , Replaced By: A0009971120
254
COVER SHIFT CASE
257
GASKET SHIFT CASE
257
GASKET , Replaced By: A0002685880
260
SCREW , Replaced By: N304017008016
260
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
263
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
263
SPRING WASHER , Replaced By: N000137008212
266
DETENT , Replaced By: A0002602173
266
DETENT SHIFT CASE
269
LOCK PLATE SHIFT CASE
272
COVER LATERAL
275
GASKET LATERAL
275
GASKET , Replaced By: A0002685580
278
SCREW BRACKET TO TAIL LAMP BRACKET
281
SPRING WASHER ALTERNATOR CONNECTION D+
