Поз.
Артикул
Описание
5
TRANSMISSION CASE ,110286
8
COVERING CASE COVER
8
COVERING , Replaced By: A0002623729
11
SPACER WASHER , Replaced By: A0012629552
11
SPACER WASHER , Replaced By: A0012629352
11
SPACER WASHER , Replaced By: A0012629152
11
SPACER WASHER , Replaced By: A0012629352
11
SPACER WASHER , Replaced By: A0012629352
11
SPACER WASHER DRIVE SHAFT,AS REQUIRED 2.70 MM
11
SPACER WASHER DRIVE SHAFT,AS REQUIRED 3.20 MM
11
SPACER WASHER DRIVE SHAFT,AS REQUIRED 3.60 MM
11
SPACER WASHER DRIVE SHAFT,AS REQUIRED 4.00 MM
11
SPACER WASHER DRIVE SHAFT,AS REQUIRED 2.20 MM
14
TAPERED ROLLER BEARING FRONT
17
SEAL RING HOUSING,INSIDE
17
SEAL RING , Replaced By: A0079975647
20
SEAL RING , Replaced By: A0079975547
20
SEAL RING OUTSIDE
23
FLANGE ON ENGINE END, 5 S 110 GPA 131097 5 K 110 GPA 131453
23
FLANGE PROPELLER SHAFT TO ENGINE,003529,5 S 90 GPA001872,5 K 90 GPA
26
THRUST WASHER FLANGE TO SHAFT
29
SCREW CLAMP TO EXHAUST PIPE
29
SCREW END PIECE TO EXHAUST PIPE M 10X25
32
LOCK FLANGE TO SHAFT
35
GASKET , Replaced By: A0002620980
35
GASKET , Replaced By: A0002622280
35
GASKET TRANSMISSION CASE COVER TO TRANSMISSION CASE
41
SCREW REAR EXHAUST PIPE TO MUFFLER
41
SCREW BRACKET TO SIDE MEMBER IN FRONT OF AXLE I M 18X40
44
SPRING WASHER BELL HOUSING WITH TRANSMISSION TO INTERMEDIATE FLANGE
44
SPRING WASHER STEERING COLUMN BRACKET TO CAB
47
BRAKE DISC CLUTCH BRAKE
47
BRAKE DISC , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002550501
47
BRAKE DISC , Replaced By: A0002550401
50
PIN , Replaced By: A3049910101
50
PIN GEAR
53
SHIM NMV INPUT
56
PISTON , Replaced By: A0002670718
56
PISTON CLUTCH BRAKE
59
COVER CLUTCH BRAKE
62
SCREW BRACKET TO FRAME SIDE MEMBER
62
SCREW , Replaced By: N304017010033
62
SCREW , Replaced By: A0002620271
62
HEXAGON HEAD BOLTM10X40, TO BE ADAPTED DURING ASSEMBLY, Replaced By: N304017010036
62
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
65
SPRING WASHER STEERING COLUMN BRACKET TO CAB
68
SCREW PLUG BELL HOUSING
68
PLUG , Replaced By: A0009973435
68
PLUG , Replaced By: A0009977535
68
PLUG , Replaced By: A3529970032
68
COVER , Replaced By: A0009977535
71
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
74
SCREW PLUG TOP AND BOTTOM
77
SCREW PLUG
80
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
83
SCREW PLUG OIL DRAIN, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
