Поз.
Артикул
Описание
1
WHEEL BRAKE CYLINDER ,A 006670
1
WHEEL BRAKE CYLINDER , Replaced By: A0034207718
2
SPRING , FOR 002 420 76 18,003 420 77 18
3
PROTECTIVE CAPTO 002 420 76 18,003 420 77 18, UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
3
PROTECTIVE CAP , Replaced By: A3164210087
4
THRUST PINTEVES
5
VALVE CLUTCH SLAVE CYLINDER
5
VALVE , Replaced By: A3075530107
6
PROTECTIVE CAP ,5 962906
6
PROTECTIVE CAP , Replaced By: A0004217187
7
REPAIR KITTO 002 420 76 18,003 420 77 18, UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
8
PROTECTIVE PLATE , FOR 002 420 77 18,003 420 78 18
9
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
10
SCREW BRACKET TO SIDE MEMBER
11
BRAKE ANCHOR PLATE
11
BRAKE ANCHOR PLATE , Replaced By: A3524200516
12
INSPECTION HOLE COVER
13
RIVET
14
ADJUSTING PIN , Replaced By: A3025860042
14
ADJUSTING PIN , Replaced By: A3024230619, +004A3024210329, +004A3124211073
15
NUT , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
16
SPRING ADJUSTING ECCENTRIC TO BRAKE ANCHOR PLATE, 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
17
WASHER , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
18
OIL COLLECTOR , 10/20 FROM IDENT NO. 796991,50/60 FROM IDENT NO. 790759 ALSO INSTALLED ON 500001-599999
18
OIL COLLECTOR , Replaced By: A3553340082
19
BRAKE SHOE , Replaced By: A3534200019
19
BRAKE SHOE , Replaced By: A3534200819
19
BRAKE SHOE , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
19
BRAKE SHOE , Replaced By: A3534200819
20
BRAKE LINING (PARTS KIT) (BRAKE LINING 16.30 MM,8X 353 423 01 10), UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
20
BRAKE LINING (PARTS KIT) (ASBESTOS-FREE BRAKE LINING) 15.30 MM,8X 353 423 35 10), UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
20
BRAKE LINING (PARTS KIT) (BRAKE LINING 17.30 MM,8X 353 423 02 10), UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
20
BRAKE LINING (PARTS KIT) (BRAKE LINING 15.30 MM,8X 353 423 00 10), UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
20
BRAKE LINING (PARTS KIT) (ASBESTOS-FREE BRAKE LINING) 17.30 MM,8X 353 423 37 10), UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
20
BRAKE LINING (PARTS KIT) (ASBESTOS-FREE BRAKE LINING) 16.30 MM,8X 353 423 36 10), UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
21
REPAIR KIT , Replaced By: A3384200289
21
REPAIR KIT BRAKE SHOE SHACKLE, UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
21
SHACKLE
22
PIN SHACKLE TO BRAKE SHOE
23
PIN
24
SPACER WASHER
25
SPRING
26
LOCK , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
27
PIVOT PIN SHACKLE TO BRAKE SHOE
28
LOCK RING TRANSMISSION CASE,TOP
29
SPRING , UP TO CHASSIS 910369EXCEPT FOR 501415-599999,FROM CHASSIS 910370,ALSO INSTALLED ON 501415-599999,SEE SPARE PARTS LIST 731. 3 OR 731.4
30
SPRING SHORT
31
PIN
32
FILLER
33
SPRING
33
SPRING , UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501455,FROM CHASSIS 910370 AND 501456-599999 SEE SPARE PARTS LIST 103
34
FILLER
35
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
36
NUT
999
SCREW LINE MOUNTING M 6X16
999
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
999
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING
999
NUT CHECK VALVE TO AIR RESERVOIR
999
FITTING CONNECTION "2"
999
FITTING ,4 667210
999
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SCREW APPARATUS PLATE M 6X45
999
SCREW PIPE CLAMP
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW BRACKET TO SIDE MEMBER
999
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
999
SCREW , Replaced By: N304017010055
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
SPRING WASHER PULL ROD TO BRAKE PEDAL AND TO DOUBLE LEVER
999
LOCK RING. SPRING WASHER
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER FITTING TO BRACKET
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
UNION NUT
999
UNION NUT LINE CONNECTION
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
HOLLOW SCREW HEATING CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
999
SLEEVE LINE CONNECTION
999
SLEEVE LINE CONNECTION
999
CLAMP ,K 147121, Replaced By: N000000000319
999
PIN FROM BRAKE SHAFT TO BRAKE LEVER
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N304017010002
999
SCREW SUPPORT TO CROSS MEMBER M 10X28
999
SCREW , Replaced By: N304017010028
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT PULL ROD
999
NUT STRAP TO SUPPORT,5 149419
999
NUT STRAP TO SUPPORT
999
NUT , Replaced By: N308673012002
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW BRACKET TO CAB CONSOLE,K 035197
999
SCREW BRACKET TO SIDE MEMBER
999
PIN
999
TURNBUCKLE , Replaced By: A3859960034
999
GLAND LINE CONNECTION
999
GLAND , Replaced By: A0019901967
999
TOOTHED WASHER HANDLE TO RATCHET ROD
999
RIVET
999
WASHER BEARING BRACKET TO FRAME
999
WASHER SPARE WHEEL CARRIER
999
SEAL RING LINE CONNECTION
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING LINE CONNECTION
999
SHEET METAL SCREW LINE MOUNTING
999
SCREW FRONT AXLE REGULATING SOLENOID VALVE
999
SCREW BRACKET TO BELL HOUSING
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW , Replaced By: N304017010050
999
SCREW , Replaced By: N000933008134
999
SCREW , Replaced By: N304017006027
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SCREW PLUG , Replaced By: N000908012009
999
RIVET
999
LOCK RING
999
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
WASHER , Replaced By: N000433013010
999
WASHER
999
WASHER VIBRATION ABSORBER TO BRACKET
999
WASHER , Replaced By: N000433010510
999
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WASHER HORN TO ENGINE CROSS MEMBER
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN
999
SCREW , UP TO IDENT NO. 674067 EXCEPT FOR 500001-599999, 673432, 673497, 673628,673629,673921
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW BRAKE LINE MOUNTING
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW BRACKET TO CAB CROSS MEMBER
999
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
999
WASHER BUMPER BRACKET TO COUPLING MOUTH
999
ADHESIVE FOIL GUIDE SIGN
999
GROMMET LINE MOUNTING 19/13 MM
999
NUT FROM BRAKE SHAFT TO BRAKE LEVER
999
BRACKET , Replaced By: A3812711640
999
BRACKET DELIVERY AND SUCTION LINES
999
WASHER WATER SEPARATOR
999
WASHER ANTE-FREEZE DEVICE TO STRAP
999
WASHER , Replaced By: A4219905440
999
SHIM BEARING BRACKET TO FRAME
999
CONSOLE SPRING LOAD ACCUMULATOR CYLINDER
999
CLAMP , Replaced By: N916016008200
999
BRACKET DISTRIBUTOR
999
BRACKET DISTRIBUTOR
999
LEVER RIGHT,2 068748
999
LEVER , Replaced By: A3604260711
999
LEVER AT BRACKET, 674067
999
BRAKE LEVER HAND BRAKE
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
REPAIR KIT , Replaced By: A3584200182
999
BRACKET AT BRAKE LINE COUPLING
999
BRAKE ANCHOR PLATE RIGHT, UP TO CHASSIS 910369 ALSO INSTALLED ON 500000-501414 FROM CHASSIS 501456-599999 AND FROM CHASSIS 910370 SEE UNIT MICROFICHE 744.300
999
BRAKE ANCHOR PLATE , Replaced By: A3584200917
999
REPAIR KIT BRAKE SHOE MOUNTING BOLT
999
ROD REAR
999
SCREW , Replaced By: A3544230171
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3534200019, +002A3534232810, +016A3079900197
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3524200019, +002A3534232710, +016A3079900197
999
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
999
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
NUT , Replaced By: A3589900051
999
SHIM , Replaced By: A3604750484
999
LEVER , Replaced By: A3524301323
999
LEVER , Replaced By: A3604260711
999
LINE , Replaced By: A3404204529
999
LINE , Replaced By: A3404204829
999
BRAKE INTERMEDIATE SHAFT REAR
999
LEVER , 656999
999
REPAIR KIT , Replaced By: A3585860242
999
LINE FROM DISTRIBUTOR TO VALVE 4200 MM,4 478330
999
LINE FROM DISTRIBUTOR TO VALVE 3600 MM,4 478330
999
REPAIR KIT , Replaced By: A3384200082
