Поз.
Артикул
Описание
1
RESERVOIR WITH WARNING DEVICE,4 314610
1
RESERVOIR LESS WARNING DEVICE ATE
1
RESERVOIR LESS WARNING DEVICE FAG
1
RESERVOIR LESS WARNING DEVICE ATE
1
RESERVOIR0.5,680031
1
RESERVOIR0.5,680031
1
RESERVOIR WITH BRAKE SYSTEM WARNING DEVICE FAG
1
RESERVOIR LESS WARNING DEVICE FAG
1
RESERVOIR LESS WARNING DEVICE ATE
1
RESERVOIR LESS WARNING DEVICE ATE
1
RESERVOIR LESS WARNING DEVICE FAG
1
RESERVOIR LESS WARNING DEVICE FAG
2
FILLER CAP , Replaced By: A0004315133
2
FILLER CAP , Replaced By: A0004315433
2
FILLER CAP BUTTRESS THREAD
2
FILLER CAP , Replaced By: A0004316533
2
FILLER CAP , Replaced By: A0004317633
2
FILLER CAPTO 001 431 38 02,000 431 58 02
2
FILLER CAP BUTTRESS THREAD
2
FILLER CAPTO 001 431 38 02,000 431 58 02
3
SEAL RING
3
SEAL RING42X21.5 MM
3
SEAL RING42X21.5 MM
4
STRAINER , Replaced By: A0004314334
4
STRAINER
4
STRAINERTO 001 431 38 02
4
STRAINERTO 001 431 38 02
4
STRAINER
5
CLAMPTO 000 431 58 02
5
CLAMPTO 000 431 53 02
5
CLAMPTO 000 431 58 02
7
BRACKET ,845437
7
BRACKET ,845438
7
BRACKET ,680031
7
BRACKET ,845437
7
BRACKET
7
BRACKET ,845438
8
SHIM
8
SHIM
8
SHIM
12
HOSE , Replaced By: A0009978952
12
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
12
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
12
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
12
HOSE , Replaced By: A0009978952
12
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
13
LINE1405 MM
13
LINE1405 MM
13
LINE3400 MM
13
LINE3400 MM
13
LINE1400 MM
13
LINE1400 MM
13
LINE1500 MM,845437
13
LINE1175 MM,845438
13
LINE1550 MM
13
LINE1650 MM
13
LINE1365 MM,845438
13
LINE1650 MM
13
LINE1500 MM,845437
13
LINE385 MM,680031
13
LINE1550 MM
13
LINE1650 MM
13
LINE1650 MM
13
LINE1510 MM,845438
15
HOLLOW SCREW
16
CONNECTOR
17
SEAL RING LINE CONNECTION
21
BRACKET
21
BRACKET
22
CLAMP
22
CLAMP
22
FIXING CLAMP. CLAMP ,845437
22
CLAMP
22
FIXING CLAMP. CLAMP ,845437
23
BRACKET , Replaced By: A3525422840
23
BRACKET BATTERY CABLE MOUNTING
24
GROMMET
24
GROMMET ,D 314239
24
GROMMET TACHOGRAPH OR SPEEDOMETER
24
GROMMET
24
GROMMET
24
GROMMET TACHOGRAPH OR SPEEDOMETER
999
SCREW BRACKET TO CAB CROSS MEMBER
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW , UP TO CHASSIS 680031 EXCEPT FOR:500001-599999
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
999
SCREW EXHAUST BRAKE SEPARATION POINT
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SHEET METAL SCREW BRACKET TO CAB
999
SHEET METAL SCREW STARTING CHANGE-OVER
999
INSULATING HOSE FROM FITTING TO INSTRUMENT CLUSTER
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
CLAMP HOSE TO FITTING
999
CLAMP LINE MOUNTING,4 257007
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N913002006009
999
NUT OIL TANK TO BRACKET
999
SCREW PLUG , Replaced By: A0004315433
999
STRAINERTO 002 430 31 01
999
RESERVOIRTO 344 430 79 01
999
RESERVOIR , Replaced By: A0014317702, +001A0004315433
999
STRAINER , Replaced By: A0004313134
999
FITTING
999
LOOM TIE LINE MOUNTING
999
HOSE , Replaced By: A0009978952
999
HOSE , Replaced By: A0009978952
999
HOSE , Replaced By: A0009978952
999
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
999
LINE , Replaced By: A3524206628
999
LINE , Replaced By: A3524206628
999
LINE , Replaced By: A3524207730
999
LINE , Replaced By: A3524207830
999
LINE , Replaced By: A3524207830
999
LINE , Replaced By: A3524207830
999
LINE , Replaced By: A3524208230
999
SCREW
999
CLAMP BRAKE LINE TO BRACKET, UP TO CHASSIS 680031 EXCEPTO FOR:500001-599999
999
LINE , Replaced By: A0004292201
999
BRACKET
999
SPACER TUBE , UP TO IDENT NO. 680031 EXCEPT FOR:500001-599999
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
CLAMP LINE MOUNTING
999
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
CLAMP , Replaced By: A3609951201
999
CLAMP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3604292940
999
CLAMP FLEXIBLE SHAFT TO CAB,335866
999
CLAMP , Replaced By: A6739950001
999
CLAMP
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
