Поз.
Артикул
Описание
65
RUBBER MOUNTING INTERMEDIATE BEARING NO.1
120
GASKET
122
UNIVERSAL JOINT ,4 805070
122
UNIVERSAL JOINT
124
GREASE NIPPLE
124
GREASE NIPPLE , Replaced By: N071412008102
135
PROPELLER SHAFT , BEARING BUSHING O..D.,45 MM, Replaced By: A3854102107
135
PROPELLER SHAFT FROM REAR AXLE I TO REAR AXLE II 740 MM,5 249277,184 KW (250 PS) 625.0055 322984,184 KW (250 PS) 625.009 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
139
UNIVERSAL JOINT , BEARING BUSHING O..D.,45 MM
150
HEXAGON HEAD BOLT , Replaced By: A0029902704
150
SCREW , Replaced By: N308676012013
152
LOCK WASHER FITTING TO BRACKET
154
NUT , Replaced By: N308673012002
154
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
GREASE NIPPLE
999
GREASE NIPPLE , Replaced By: N071412008102
999
UNIVERSAL JOINT CROSS WITH BUSHINGS
999
PROPELLER SHAFT FROM INTERMEDIATE BEARING II TO REAR AXLE 970 MM,4 839393 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
DRIVE FLANGE
999
DRIVE FLANGE
999
PROPELLER SHAFT FROM VOITH RETARDER TO REAR AXLE 890 MM
999
UNIVERSAL JOINT CROSS , Replaced By: A9734100031
999
PROPELLER SHAFT , Replaced By: A3974100107
999
PROPELLER SHAFT , BEARING BUSHING O..D.,45 MM, Replaced By: A3854106307
999
DRIVE FLANGE , SHAFT TO BE BALANCED AFTER REPAIR4 805070
999
DRIVE FLANGE
999
LOCK1.800 MM
999
LOCK1.775 MM
999
LOCK1.700 MM
999
SCREW CROSS MEMBER AND GUSSET PLATE TO SIDE MEMBERS M 12X35
999
BEARING BUSHING , SHAFT TO BE BALANCED AFTER REPAIR4 805070
999
UNIVERSAL JOINT CROSS
999
LOCK AS REQUIRED 1.85 MM
999
LOCK AS REQUIRED 1.80 MM
999
LOCK AS REQUIRED 1.70 MM
999
LOCK , Replaced By: A0069941441
999
LOCK , Replaced By: A0069941241
999
LOCK , Replaced By: A0069940841
999
NEEDLE
