Поз.
Артикул
Описание
10
DIFFERENTIAL GEAR
20
DIFFERENTIAL CASE
30
SIDE GEARTO 345 353 71 14,CONIFLEX, ONLY REPLACEABLE BY THE SET
40
DIFFERENTIAL PINIONTO 345 353 72 15,CONIFLEX, ONLY REPLACEABLE BY THE SET
50
DIFFERENTIAL SPIDER , Replaced By: A3603530020
60
THRUST WASHER DIFFERENTIAL PINION 1.50X30 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
60
THRUST WASHER DIFFERENTIAL PINION 1.50X30 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
60
THRUST WASHER , Replaced By: A3273534662
70
THRUST WASHER STEEL 1.80 MM
70
THRUST WASHER STEEL 1.70 MM
70
THRUST WASHER STEEL 1.65 MM, TO REAR AXLES 360 350 88 00, 345 350 48 00,345 350 88 04
70
THRUST WASHER STEEL 1.60 MM, TO REAR AXLES 360 350 88 00, 345 350 48 00,345 350 88 04
70
THRUST WASHER STEEL 1.55 MM
70
THRUST WASHER STEEL 1.50 MM, TO REAR AXLES 360 350 88 00, 345 350 48 00,345 350 88 04
70
THRUST WASHER STEEL 1.45 MM
70
THRUST WASHER DIFFERENTIAL GEAR 1.80 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
70
THRUST WASHER AS REQUIRED 1.70 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
70
THRUST WASHER BRASS 1.65 MM
70
THRUST WASHER1.60 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
70
THRUST WASHER BRASS 1.55 MM
70
THRUST WASHER1.50 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
70
THRUST WASHER BRASS 1.45 MM
70
THRUST WASHER , Replaced By: A3273533762
70
THRUST WASHER , Replaced By: A3273533662
70
THRUST WASHER , Replaced By: A3273533562
70
THRUST WASHER , Replaced By: A3273533462
70
THRUST WASHER , Replaced By: A3273533362
70
THRUST WASHER , Replaced By: A3273533162
70
THRUST WASHER , Replaced By: A3273533262
80
SET COLLAR
90
REAR AXLE SHAFT BRAKE DRUM TO REAR WHEEL HUB
100
OIL COLLECTOR
110
SHIFTING FORK DIFFERENTIAL LOCK
120
FOLLOWER BELL HUB
130
BEARING BUSHING SHIFTING FORK TO REAR AXLE HOUSING
140
SEAL RING SHIFTING FORK TO REAR AXLE HOUSING
150
PAD , Replaced By: A3273510119, +002A3273510019
150
PAD SHIFTING FORK TO REAR AXLE HOUSING 0.50 MM
150
PAD SHIFTING FORK TO REAR AXLE HOUSING 0.10 MM
160
PROTECTIVE CAP SHIFTING FORK TO REAR AXLE HOUSING
170
LEVER
170
LEVER DIFFERENTIAL LOCK
180
SCREW , TO REAR AXLES 360 350 88 00, 345 350 48 00,345 350 88 04
190
NUT LEVER TO SHIFTING FORK
200
BRACKET SHIFTING CYLINDER
200
BRACKET LEVER TO SHIFTING FORK
210
SCREW
220
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
230
PIN TWO-SPEED REAR AXLE
240
LOCK , FIRST EXHAUST STOCK OF OLD PARTS UP TO REAR AXLE 3 132029, Replaced By: A3279940115
250
SWITCH BACK-UP LIGHT
250
SWITCH , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3455457006
250
SWITCH SOLENOID VALVE
260
CYLINDER , Replaced By: A3843537055, +002N007603010406, +001N915036006101, +001N915052004016
260
CYLINDER ONE-CHAMBER COMPRESSED AIR CYLINDER SCHRADER
260
CYLINDER ONE-CHAMBER BOSCH
270
BUSHINGBOSCH
280
BOOTBOSCH
290
BUSHINGTO 000 353 02 55, 345 353 70 55, 71 55
290
BUSHINGBOSCH
300
SEAL RING COMPRESSED AIR CYLINDER TO BRACKET BOSCH
310
PROTECTIVE CAPTO 345 353 71 55, 70 55
310
PROTECTIVE CAPTO 345 353 70 55, 71 55
310
BOOTBOSCH
320
NUT
330
REPAIR KIT , Replaced By: A0003500084
330
REPAIR KIT , Replaced By: A0003500184
330
REPAIR KITTO 345 353 71 55
330
REPAIR KITTO 345 353B 70 55
340
YOKE COMPRESSED AIR CYLINDER TO BRACKET
350
PIN CYLINDER TO SHIFTING FORK
360
LOCK PLATE CYLINDER TO SHIFTING FORK
370
WASHER COMPRESSED AIR CYLINDER TO BRACKET
380
LOCK PLATE CYLINDER TO SHIFTING FORK
999
SCREW COLLAR DIFFERENTIAL GEAR ADJUSTMENT
999
DIFFERENTIAL GEAR , Replaced By: A3503502723
999
BRACKET , Replaced By: A3383500138
999
FLANGE REAR AXLE HOUSING
999
GASKET AXLE HOUSING
