Mercedes A0139900701 - Болт

OH 1518, 1521, 1526 368.006

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 885 AIR CONDITIONER ATTACHMENT PARTS IL. 2

Поз.
Артикул
Описание
130
A0131545002
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY "BOSCH" 28V/80A
140
A0001541849
BEARINGTO 013 154 50 02
150
A0009901206
SCREW
160
A0089818425
BALL BEARING
170
A0001540452
SPACER WASHER
180
A0001548415
ROTORTO 013 154 50 02
190
A0089818625
BALL BEARING REAR
200
A0001548525
COILTO 013 154 50 02
210
A0001541949
BEARINGTO 013 154 50 02
220
A0011544216
RECTIFIERTO 013 154 50 02
230
A0001542705
REGULATORTO 013 154 50 02
240
A0139900601
SCREW
250
A0019906121
SCREW REGULATOR AND CUT-OUT
260
A0139900701
SCREW
270
A0009902003
BOLT. SCREW
280
A0011555115
PULLEYTO 013 154 50 02
290
A0009905348
WASHER PULLEY TO ALTERNATOR
300
A0059904151
NUT
310
A0001544904
COVERTO 013 154 50 02
320
A0059903651
NUT
330
A0059903451
NUT BOOT M8,BOSCH
350
A0019905421
SCREW PARTS KIT TO 012 154 67 02/68 02, Replaced By: A0009905899
